ILLUSTRATED PARTS LIST IP46
G4TP1, ILLUSTRATED PARTS/RECOMMENDED PARTS 060117A
ITEM # PART # DESCRIPTION
1A WC-37122
1
KIT, DUMP VALVE RIGHT
1B WC-854
2
VALVE, BREW DUMP RIGHT 240V 12W
GEM12D/TP/TPC
2A WC-37121
1
KIT, DUMP VALVE LEFT
2B WC-853
2
VALVE, BREW DUMP LEFT 240V 12W GEM12D/
TP/TPC
3A WC-442
1
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
3B WC-446
2
SOLENOID, LOCK BREW CONE RIGHT 220V
THERMOPRO/GEMTS
4A WC-2977K
a
KIT, SPRAYHEAD FITTING METAL
4B WC-2977-101K
b
KIT, SPRAYHEAD FITTING PLASTIC
5A WC-844-101
1
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
5B WC-844-102
2
VALVE, BY-PASS, 240V NON-ADJUSTABLE W/
RESTRICTOR (WC-2945)
6 WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR
7 WC-10000 CONTROL MODULE, TOUCH SCREEN G4
8 WC-10001 CONTROL MODULE, UPM 120/220V G4
9 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
10 WC-8559
RELAY, SOLID STATE 280V/40A W/ HEATSINK
AND QUICK DISCONNECTS
11 WC-3417
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12A WC-58037-102 COVER, FRONT CENTER G4TP1S
12B WC-58037-102BLK
COVER, FRONT CENTER BLACK TEXTURE
G4TP1S
12C WC-58037-102WHT COVER, FRONT CENTER WHITE G4TP1S
13 WC-2402P ELBOW, 3/8”FL x 3/8” NPT PLATED
14 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
15 WC-14045-101 CURRENT SENSOR ASSY G4
16A WC-13450
1
HARNESS ASSY, COMPLETE G4TP2T
(INCLUDES TERMINAL BLOCK)
16B WC-13450-101
2
HARNESS ASSY COMPLETE G4TP2T
G4TPC2T/G4GEMT/G4TP1T-30’S (INCLUDES
TERMINAL BLOCK)
ITEM # PART # DESCRIPTION
17 WC-29044 SLEEVE, OVERFLOW ASSY GEN USE
18 WC-3765L
KIT, INLET VALVE REPAIR USE ON WC-826/
WC-826L/WC-847 (OLDER UNITS)
19A WC-847
1
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
19B WC-883
2
VALVE, INLET 2 GPM 240V 6W
20 WC-596K
2
KIT, NOISE FILTER EMI 250V/30A 1PH
21 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
22A WC-102
1
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
22B WC-103
2
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
23A WC-5459 COVER, TOP SS THERMOPRO
23B WC-5459-BLK COVER, TOP BLACK TEXTURE TP
23C WC-5459-WHT COVER, TOP WHITE TP2T
24 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
25 WC-1825 FAUCET, ASSY HOT WATER TP2S
26 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
27 WC-5231 COMPOUND, SILICONE 5 OZ
28 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
29A
1
WC-589-101
TRANSFORMER,120VAC-24V 4.8A W/ LEADS &
MOLEX CONNECTOR
29B
2
WC-589-102
TRANSFORMER,240VAC- 24V 4.8VA W/LEADS
& MOLEX CONNECTOR
30 WC-10008 UNIVERSAL HOST ADAPTER USB
31 WC-3518 LEG, GLIDE 3/8”-16 STUD SCREW
32A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
32B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
33A WC-4213
a
NUT, 5/8 LOCK PLATED
33B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
G4TP1T - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
1A WC-37122 KIT, DUMP VALVE RIGHT
2A WC-37121 KIT, DUMP VALVE LEFT
3A WC-442
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
5A WC-844-101
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
8 WC-10001 CONTROL MODULE, UPM 120/220V G4
ITEM # PART # DESCRIPTION
9 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
15 WC-14045-101 CURRENT SENSOR ASSY G4
19A WC-847
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
26 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
28 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
G4TP1T - Recommended Parts to Stock
1
G4TP1T10A3100
2
G4TP1T30A3100
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWKROGHUXQLWV
b
Units built before 05/15/17.
