Curtis GEMSIF30A1000 [22/42] Gemtif main chassis parts list

Curtis GEMSIF30A1000 [22/42] Gemtif main chassis parts list
ITEM # PART # DESCRIPTION
1 GEM3IF
SATELLITE SERVER, 1-1/2 GAL. 75W 120V .60A
W/INTELLIFRESH
2A* WC-37121
1,2
KIT, DUMP VALVE LEFT
2B WC-853
3
VALVE, BREW DUMP LEFT 240V 12W GEM12D/
TP/TPC
3A WC-442
1,2
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
3B WC-446
3
SOLENOID, LOCK BREW CONE RIGHT 220V
THERMOPRO/GEMTS
4A* WC-2977K
a
KIT, SPRAYHEAD FITTING METAL
4B WC-2977-101K
b
KIT, SPRAYHEAD FITTING PLASTIC
5A* WC-844-101
1,2
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
5B WC-844-102
3
VALVE, BY-PASS, 220V NON-ADJUSTABLE W/
RESTRICTOR (WC-2945)
6A WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR (OLDER
UNITS)
6B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
(NEWER UNITS)
7A WC-723
1,2
CONTROL MODULE, UCM 120V TP2S /TP2T
GEMSS/GEMTS
7B WC-728
3
CONTROL MODULE, UCM 220V TP2S/ TP2T/
GEMSS/GEMTS
8A* WC-39744
LABEL, UCM OVERLAY DUAL TWIN 3-BATCH
GEMTIF
8B* WC-39756
LABEL, UCM OVERLAY PANEL 2-BATCH GEMTIF
CURTIS
8C* WC-39755
LABEL, UCM OVERLAY PANEL 1-BATCH GEMTIF
CURTIS
9* WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
10* WC-8559
RELAY, SOLID STATE 280V/40A W/ HEATSINK
AND QUICK DISCONNECTS
11* WC-3417
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12 WC-39745 LABEL, BOTTOM PANEL GEMTIF
13A WC-61959
1,3
COVER, FRONT GEMTIFSS
13B WC-61959-BLK
2
COVER, FRONT GEMTIFBLK
14 WC-61963 PLATE, HOLDER IF CONNECTORS GEMTIF
15 WC-38504
LABEL, WARNING SHOCK HAZARD INTELLI-
FRESH
16 WC-61961 DECK, WARMER GEMTIFSS NEW
17 WC-29044-101 SLEEVE, OVERFLOW
18* WC-2402P ELBOW, 3/8"FL x 3/8" NPT PLATED
19A* WC-847
1,2
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
19B WC-883
3
VALVE, INLET 2 GPM 240V 6W
ITEM # PART # DESCRIPTION
20A* WC-37122
1,2
KIT, DUMP VALVE RIGHT
20B WC-854
3
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/
TP/TPC
21* WC-1501 FUSE, HOLDER ASSY W/5A FUSE
22A* WC-102
1,2
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
22B WC-103
3
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
23A WC-61955
1,3
COVER, TOP SSTL GEMTIF
23B WC-61955-BLK
2
COVER, TOP GEMTIF BLK
24* WC-3528
LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
25* WC-1809
FAUCET, PS/HPS SERIES HOT WTR 1/2-20 UNF
AP/ALP
26* WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
27* WC-5231 COMPOUND, SILICONE 5 OZ
28 WC-571K-R KIT, IF CONNECTOR- RIGHT
29 WC-571K-L KIT, IF CONNECTOR- LEFT
30 WC-43133
O-RING, 1.424ID X 1.630 OD X .103 WALL
GEMIF’s
31* WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
32 WC-1250
3
CORD, 4mm² 90ºC 49A 450/750V 6 FT LG W/
FERRULES ONE END (NOT SHOWN)
33A WC-13335
1,2
HARNESS ASSY, COMPLETE TP2T10/ GEMTS
FOR SOLID STATE RELAY (INCLUDES
TERMINAL BLOCK)
33B WC-13338
3
HARNESS ASSY, COMPLETE TP2T30 GEMTS
FOR SOLID STATE RELAY (INCLUDES
TERMINAL BLOCK)
34 WC-596K
3
KIT, NOISE FILTER EMI 250V/30A 1PH
35A WC-61954
1,3
PLATE, BREW CONE STOP SSTL GEMTIF
35B WC-61954-BLK
2
PLATE, BREW CONE STOP GEMTIF BLK
36 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
37A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
37B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
38A WC-4213
a
NUT, 5/8 LOCK PLATED
38B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
39 WC-314 POWER BLOCK, 5 STATION
40A WC-8591
1,2
CAPACITOR, X2 USED ON ALL ADS MODELS
40B WC-8609
3
CAPACITOR, 2.2 UF 250/275 VAC 50/60 ALL
ARU’S
GEMTIF - Main Chassis - Parts List
ILLUSTRATED PARTS LIST IP2
1
GEMTIF10A1000,
2
GEMTIF10B1000,
3
GEMTIF30A1000
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWK
older units.
b
Units built before 05/15/17.
5HFRPPHQGHGSDUWVWRVWRFN
GEMSIF/GEMTIF - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 120417D
