5
벽걸이 브라켓
본체 설치 스크류벽걸이 설치 스크류
본체( CAV-705U)
PHM 3 X 6 ZnYGH1T 4 X 50 ZnY
연결 컨넥터
2P(3EA)
POWER CORD 480 장원원형 단짹
연결 컨넥터
3P(1EA)
연결 컨넥터
4P(1EA)
MANUAL
사용설명서
연결 컨넥터
6P(2EA)
연결 컨넥터
8P(1EA)
연결 컨넥터
12P(1EA)
4. Compositions
▲
Monitor
GH1T 4X18 ZNW
Screws for mounting
Screws for main body
Connectors Connectors Connectors
ConnectorsConnectorsConnectors
▲
Wall bracket
▲
User manual
www.safemag.ru
www.safemag.ru
