To manage unit numbers at Floor Distributors (CCU-204AG/232AG).

※ This function is enabled when Floor distributors are installed.

※ While conducting this function on the Floor distributor,

the lobby phone connected to the Floor Distributor does not work.

To upload household unit numbers

※ Uploading household numbers to the Floor Distributor is enabled via

security station.

1) Connect a PC to the RS-232 port of security station.

2) Execute a program provided by COMMAX and input data of household

unit number.

Execute the program number 06 at the security station to turn on the data

receiving mode.

4) As you send the date from the PC, the household unit number data is

updated at the Floor Distributor via security station.

To download household unit numbers

※ Downloading household numbers from the Floor Distributor is enabled

via security station.

1) Connect a PC to the RS-232 port of security station.

2) Execute a program provided by COMMAX.

3) Execute the program number 05 at the security station to turn on the data

receiving mode.

4) Enter “9700” in the Building number section and press “*”(Building

button).

5) Enter the ID of the Floor Distributor and press “#”(Paging button) to start

downloading household unit number data.

※ PC must be connected to the security station via RS232 port.

If not, downloading process will be at standing-by mode.

6) Data can be revised in the PC program.

Tip) To change the unit number data without a PC after downloading

1) After downloading the household unit number data from the Floor

Distributor via a security station, use (◀ or ▶) buttons to select the data

to be changed.

2) After selecting the household unit number to change, press “Input”

button.

3) As cursor appears, use (◀ or ▶) buttons to change the data.

4) After change is made, press “Remote” button.
