5) Uploading the revised data to the Floor Distributor starts.

Setting the function of DTMF

※ You can use the keypad to call the guard(or other household unit) or

open the door if household unit device is phone with keypad.

1) After downloading the household unit number data from the Floor

Distributor via a security station, use (◀ or ▶) buttons to select the unit

what use the function of DTMF.

2) Change the Sub-Number to '1'(Number one)

ex) '0101-0001 1234 0'

(101[Building number], 1[Household number], 1234[Password], 0[Sub-

Number] )

 Change to '0101-0001 1234 1'

3) You can use the keypad to call or open.

To manage household unit data at a lobby phone

※ This function is enabled only if the lobby phone has name storing

function available.

※ While conducting this function, the lobby phone is not functional.

To upload the name information

※ Uploading data is enabled via a security station.

1) Connect a PC to the RS-232 port of security station.

2) Execute a name information input program and enter data

3) Execute the program number 06 at the security station to turn on the data

receiving mode.

4) As you send the date from the PC, the name information data is updated

at the lobby phone via security station.

To download the name information

※ Downloading data is enabled via a security station.

1) Connect a PC to the RS-232 port of security station.

2) Execute a name information input program.

3) Execute the program number 05 at the security station to turn on the data

receiving mode.

4) Enter the building number and press“*”(Building button).

Enter the ID of the lobby phone and press “#”(Paging button) to start

downloading the name information data.

※ PC must be connected to the security station via RS232 port.

If not, uploading process will be at standing-by mode.

6) Data can be revised in the PC program.

※ The name information cannot be changed at the security station.
