Table of Contents

1. Feature ..............................................................................................................1

2. Warnings and caution.........................................................................................2

3. The name & Function ........................................................................................4

4. Manual to use.....................................................................................................5

5. System Diagram.................................................................................................9

6. wiring................................................................................................................10

7. Precautions. .....................................................................................................11

If a CCU-232AGF is installed among CCU-204AGFs, It has to be used by

connecting 8-wires among floor distributors for power supply among CCU-

204AGFs.

●

This unit can be used by connecting with the 2-wire loop type Interphone

(ex. AP-2SAG) manufactured in COMMAX.

●

This unit can be also used by connecting with Phone what has a keypad.

●

This unit connect with a lobby phone in 6-wires.

●

This unit s using a Power of DC24V/3A(Recommended RF-24AS by COMMAX).
