1. Choose a location where you install the Monitor. Clean the place for the Stand with cleanser
and remove the Protective Tape. And then attach it exactly where you want.
2. Fasten the Monitor with Tapping Screw.
3. Adjust angle of Stand and install Monitor.
4. Connect each connecting cable as in the product installation reference.
Monitor Cable Connection
6. Installation
Cable Guidance
Fix Knob
(Bracket)
Tapping Screw
Safeguard tape
Control Knob
(Angle)
Stand Base
* Installed on the ceiling * Normal Installation
