2
G Operating instruction
Thank you for choosing a Hama product.
Take your time and read the following instructions and information completely. Please keep
these instructions in a safe place for future reference. If you sell the device, please pass
these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic
hazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
• TV wall bracket
• TV support arms (2x)
• Installation kit (see contents, Fig. 1)
• These operating instructions
Note
Please check that the installation kit is complete before installing the bracket and
ensure that none of the parts are faulty or damaged.
3. Safety Notes
Warning
• Given the multitude of terminal devices and wall structures available on the
market, the supplied mounting kit is unable to cover every option.
• It occasionally happens that the screws for attaching the terminal device to the
wall bracket are too long.
• Please note that the supplied wall plugs are for use with concrete brick and solid
brick walls only.
• Read the operating instructions for your terminal device before attempting to
mount it. The instructions provide information about the type and measurements
of suitable fastening materials.
• If the supplied mounting kit does not contain suitable fastening materials for
mounting the terminal device, purchase these from a specialised dealer.
• If the wall on which the bracket is to be mounted is made of different material
types and construction types to those specied, purchase suitable mounting
materials from a specialised dealer.
• Never apply force during mounting. This can damage your end device or wall
bracket.
• If in doubt, have this product mounted by a qualied technician - do not attempt
to mount it yourself!
• Do not mount the product above locations where persons might linger.
• Once you have mounted the product and the attached load, check that they are
suciently secure and safe to use.
• You should repeat this check at regular intervals
(at least every three months).
• When doing so, ensure that the product does not exceed its maximum permitted
carrying capacity and that no load exceeding the maximum permitted dimensions is
attached.
• Make sure that the product is loaded symmetrically.
• Maintain the necessary safety clearance around the attached load (depending on the
model).
• In the event of damage to the product, remove the attached load and stop using the
product.
4. Intended use and specifications
• The bracket is used for wall mounting at panel displays for non-commercial, private
household use.
• The bracket is only intended for use within buildings.
• Use the bracket only for the intended purpose.
Maximum load bearing capacity: 25 kg
Screen size: 48 – 122 cm (US: 19" – 48")
Depth: 2.9 cm
Wall mounting plate dimensions: 22.0 x 9.6 cm
Mounting holes: according to the VESA standard until: 200x200
5. Installation requirements and installation
Note
• Only mount the TV wall bracket with the help of a second person. Get the support
and help you need.
• Different end devices have different options for connecting cables and other
devices. Before installation, ensure that the necessary connections will still be
accessible after installation.
• The same mounting kit is included with all of our TV wall brackets. Depending on
the product and mounting type, you may not need to use the entire mounting kit.
Unneeded screws and other small parts may be left over, even if the wall bracket
is properly mounted. Keep these leftover parts with the operating instructions in a
safe place, just in case you might need them later on (e.g. should you move, sell
the product, mount the wall bracket in a different location, buy a new TV, etc).
Warning
• Before installing the bracket, ensure that the wall on which the television is to be
mounted is suitable for the weight and make sure that no electrical wires, water,
gas or other lines are located at the installation location.
• Please note that the provided wall anchors are only approved for concrete and
solid brick walls.
• Observe the other warnings and safety instructions.
• Proceed step-for-step in accordance with the illustrated installation instructions (Fig.
1 ff.).
6. Setting and maintenance
Note
Only adjust the TV wall bracket with the help of a second person. Get the support and
help you need.
• To adjust the inclination, loosen the side mounting screws slightly, set the desired angle
and retighten the screws securely.
• Check that the bracket is secure and safe to use at regular intervals (at least every three
months). Only use water or standard household cleaners for cleaning.
• To secure, insert the carrying arms into the wall plate and tighten both screws.
7. Warranty Disclaimer
Hama GmbH & Co. KG assumes no liability and provides no warranty for damage resulting
from improper installation/mounting, improper use of the product or from failure to
observe the operating instructions and/or safety notes.
8. Service and Support
Please contact Hama Product Consulting if you have any questions about this product.
Hotline: +49 9091 502-115 (German/English)
Further support information can be found here:
www.hama.com
