Sven 314 Черный [13/16] Usb multimedia speaker system

2. PACKAGE CONTENTS

• Speaker System — 1 pc

• Operation manual — 1 pc

• Warranty card — 1 pc

3. SAFETY PRECAUTIONS

• Do not open the MSS and do not perform repairs by yourself. Service and repairs should be performed

only by qualiﬁed specialists at authorized service centers. The list of authorized service centers is on

www.sven.ﬁ.

• Do not allow the circuit of wires (including the grounded ones) between the speakers, on the

power ampliﬁer or the ground, for it causes damage to the power ampliﬁer output stage.

• Make sure that foreign objects do not get inside the holes of the MSS.

• The product shall not be exposed to water dripping or splashing and no objects ﬁlled with liquids, such

as vases shall be placed on the product.

• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose it to

direct sunlight.

• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.

• MSS has the device of cutting oﬀ connection, easy to operate. If the МAINS plug and coupled appara-

tus used as the disconnect device, the disconnect device should be convenient to insert and pull out.

• If the MSS does not operate, unplug it and address your dealer.

4. TECHNICAL DESCRIPTION

SVEN 314 2.0 Multimedia USB Speaker System (MSS) is designed to play music and sound games,

movies, etc. The MSS has a built-in ampliﬁer, an audio cable and a signal cable enabling to connect it to

virtually any audio source (a PC, laptop, MP3 or CD player, etc.). The MSS is powered via a PC or laptop

USB port or a 5V DC power supply by means of the integrated USB cable. The speaker with an audio

input and a control panel is named «the active speaker».

MSS special features

• Compact design

• Speaker system is compatible with PCs, DVD/Media-players,

mobile devices and other sound sources

• Volume control

• USB power supply

• Headphone and microphone jacks

• ABS рlastic case of speakers

Control panel

a LED: power LED

b POWER: power switch

c VOLUME: volume control wheel

Fig. 1. Control panel

ENG

2.0 USB Multimedia

Speaker System
