If unit fails to operate properly

Carefully read the instruction to make sure the unit is being operated properly. Check the following before you

take your unit to the local dealer for repair.

Symptom Possible cause Solution

The volume control regulator set in the

minimal position

Adjust sound level

Bad power connections Check to see that all the power and speaker

leads are securely connected

No sound

The audio cassette receiver is damaged Take your unit to the local dealer for repair

Acoustic system cables are connected

without observance of polarity (+ or -)

Check to see that all the power and speaker

leads are securely connected

Damage speaker wire or speaker Replace the speaker or speaker wires

Unnatural

sound

The audio cassette receiver is damaged Take your unit to the local dealer for repair

Note: Good ground connections eliminate most electrical noise problems and require tight contact with the

metal vehicle chassis. Remove plastics, paint or rust for good electrical contact.

Specification

Loudspeaker one woofer: 10 cm (4”) IMPP cone

tweeter: 35 mm PEI dome

Magnet ferrite 5.3 Oz magnet

Peak output power 100 W

Rated output power 50 W

Impedance 4 hm

Sensitivity 91 dB

Frequency response 80 – 20000 Hz

Dimensions 133.5 x 63.5 mm

Net / Gross weight 0.45 kg / 1.08 kg

Gift box dimension 306 mm  158 mm  76 mm
