19
CHAPTER 5: Overlay description / enGineerinG mode
wORkOUT PROFILE wINDOw:
During a workout, this window displays shapes, made of triangle columns of lights, which represent the levels of intensity in a workout-in-progress. The
height of the furthest column is proportional to the current level of the intensity. Information will cycle every 30 seconds.
INSTURCTION CENTER:
This window displays step-by-step instructions for setting up a workout.
INFORMATIONAL DISPLAY:
During a workout, three sets of numbers, including Speed, Time and Distance, display statistics about the progress of the workout.
PROGRAM PLUS™ kEYS
Press the key to select one of the workouts. The program key with a symbol of plus “+” represents additional workout options. Press this key repeatedly for
similar workout options.
LEVEL ARROw kEYS
During a workout, pressing the UP or DOWN arrow can adjust intensity levels.
RIGHT / LEFT ARROw kEYS
A pair of RIGHT and LEFT arrows is located on the side of SELECT. Use arrows, when setting up a workout, to change workout parameters displayed on
the LCD console, such as length of workout, weight, age, heart rate, and intensity level. In addition, the pair of RIGHT and LEFT arrows is corresponding
to the arrows in the LCD display.
QUICk START
Press QUICK START to begin your workout immediately, without having to select a workout program.
RESET
PAUSE: If you need to PAUSE your program during a workout, stop pedaling. It will PAUSE your program for 30 seconds. Pressing START will return you
to your workout. NOTE: Pause time is only available for ellipticals equipped with the battery.
RESET: If you need to RESET the console during your workout, you can do so by holding down the RESET button for three seconds, or until the
display resets.
A)
B)
C)
D)
E)
F)
G)
H)
5.1 CONSOLE DISPLAY
A
B
C
E
F
G
H
D
R1x_U1x_081201.indd 19 12/1/08 9:40:06 AM
