9. Slide the Front Shield Cover (7) upward onto the

Upright (4).

While another person holds the Upright (4) near

the Frame (1), connect the Upper Wire (59) to

the Lower Wire (58).

Insert the Upright (4) into the Frame (1).

Tip: Avoid pinching the wires. Attach the

Upright (4) with four M8 x 20mm Screws (74)

and four M8 Split Washers (75).

Slide the Front Shield Cover (7) downward to the

Frame (1) and press it into place.

Avoid pinching

the wires

10. Identify the Right Pedal (21).

Using an adjustable wrench, firmly tighten the

Right Pedal (21) clockwise into the Right Crank

Arm (19).

Tighten the Left Pedal (not shown) counter-

clockwise into the Left Crank Arm (not shown).

Adjust the strap on the Right Pedal (21) to the

desired position, and press the ends of the

straps onto the tabs on the Right Pedal.

Adjust the strap on the Left Pedal (not

shown) in the same way.

Strap

Tab
