5. Orient the Seat (23) and the Seat Carriage (24)

as shown.

Attach the Seat (23) to the Seat Carriage (24)

with four M8 Locknuts (72) and four M8 Split

Washers (75).

Slide the Seat Carriage (24) onto the Seat

Post (6). Then, slide the Seat Carriage all the

way forward and tighten the Seat Adjustment

Knob (26).

Attach an M4 x 5mm Bright Screw (91) to the

rear of the Seat Post (6).

6. Using a plastic bag to keep your fingers clean,

apply some of the included grease to an M6 x

70mm Bolt Set (50).

Orient the Handlebar (5) and the Upright (4) as

shown.

While a second person holds the Handlebar (5)

near the Upright (4), insert the Upper Wire (59)

upward through the Handlebar.

Tip: Avoid pinching the Upper Wire (59).

Attach the Handlebar (5) to the Upright (4)

with the M6 x 70mm Bolt Set (50) and two M8

Washers (43).

Then, attach an M6 x 60mm Bolt Set (51)

through the lower bracket on the Handlebar (5).

Grease

Avoid pinching the

Upper Wire (59)
