Clarion CZ301E [10/30] System setup
![Clarion CZ301E [10/30] System setup](/views2/1003577/page10/bga.png)
9
English
System Setup
At all mode, press and hold [ D ] button to
enter system setup. Press [
] or [ ]
button to select options, rotate the [VOLUME]
knob to adjust.
AF: ON/OFF (RADIO mode)
Rotate the [VOLUME] knob to choose AF
ON or OFF.
REG: ON/OFF (RADIO mode)
Rotate the [VOLUME] knob to choose REG
ON or OFF.
DX/LO (RADIO mode)
Rotate the [VOLUME] knob to choose radio
local or distant at radio mode.
• LO: Only stations with strong signal can
be received.
• DX: Stations with strong and weak signals
can be received.
AUX SENS (AUX mode)
Rotate the [VOLUME] knob to choose AUX Input
sensitivity LOW, MID or HIGH at AUX mode.
AUTO CON: ON/OFF (BT mode)
Rotate the [VOLUME] knob to choose
AUTO CON ON or OFF.
PIN CODE
Rotate and press the [VOLUME] knob
to choose a 4-digit password. Press the
[VOLUME] knob more than 1 seconds to
conrm.
The PIN CODE default setting is “ 0000 “.
SCRN SVR: ON/OFF
Rotate the [VOLUME] knob to choose SCRN
SVR (screen saver) ON or OFF.
SCROLL: ON/OFF
For track information that is longer than the
display panel:
When SCROLL is ON, the LCD will display
ID3 TAG information cyclely, e.g: TRACK-
>FOLDER->FILE->ALBUM->TITLE-
>ARTIST->TRACK->...
When SCROLL is OFF, the LCD will display
one of the ID3 TAG information, the default
is TRACK, but user can adjust it to other ID3
TAG information by press [ D ] button.
DIMMER: ON/OFF
Rotate the [VOLUME] knob to choose
DIMMER ON or OFF.
• ON: LCD dimmer is active when small light
of vehicle is turned ON.
• OFF: LCD always maximum brightness
regardless of the vehicle small light.
REAR/S-W
Rotate the [VOLUME] knob to choose REAR
or SUB-WOOFER.
BEEP: ON/OFF
Rotate the [VOLUME] knob to choose button
beep sound ON or OFF.
MIC SEL (BT mode)
Rotate the [VOLUME] knob to choose
Microphone EXTERNAL or INTERNAL.
MIC GAIN (BT mode)
Rotate the [VOLUME] knob to choose Mic
gain: 1, 2, 3, 4, 5.
You can change the gain of MIC when a
telephone partner cannot hear your voice.
