“ When using an electrical appliance, basic safety precautions should always be followed,
including the following.”
“ Read all instructions before using this sewing machine.”
“DANGER
-
“IMPORTANT SAFETY INSTRUCTIONS”
1. “ This sewing machine should never be left unattended when plugged in. Always unplug
this sewing machine from the electric outlet immediately after using and before cleaning.”
“WARNING
-
1.
“ Do not allow to be used as a toy. Close attention is necessary when this sewing machine is
used by or near children.”
2.“This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do not play with the
appliance.”
3.“Use this sewing machine only for its intended use as described in this manual. Use only
attachments recommended by the manufacturer as contained in this manual.”
4.“Never operate this sewing machine if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. Return the sewing
machine to the nearest authorized dealer or service center for examination, repair,
electrical or mechanical adjustment.”
5.
“ If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.”
6.
“ Never operate the sewing machine with any air openings blocked. Keep ventilation
openings of the sewing machine and foot control free from the accumulation of lint, dust,
and loose cloth.”
7.
“Never drop or insert any object into any opening.”
8.
“ Indoors use only.”
9.
“Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.”
10.
“To disconnect, turn switch to the off („0“) position, then remove plug from outlet.”
11.
“ Switch off or unplug the appliance when leaving it unattended, unplug the appliance before
carrying out maintenance or replacing lamps.”
12.
“Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.”
13.
“ Keep fingers away from all moving parts. Special care is required around the sewing
machine needle.”
14.
“Never sew with a damaged needle plate as this can cause needle to break.”
15.
“Do not use bent needles.”
16.
“Do not pull or push fabric while stitching. It may deect the needle causing it to break.”
17.
“ Switch the sewing machine off (“0”) when making any adjustments in the needle area, such
as threading needle, changing needle, threading bobbin, or changing presser foot, etc.”
18.
“ Always unplug sewing machine from the electrical outlet when removing covers, lubricating,
or when making any other user servicing adjustments mentioned in the instruction manual.”
19.
“To avoid electrical shock never put the machine nor the mains cable or mains plug into
water or other liquids.”
20.
“The LED lamp maximum power is 0.3w, maximum voltage is DC 5v, if the LED lamp is
damaged, you should not use the product and send it to the manufacture or service agent
to repair or replace at once.”
21.
“ Attention the following to avoid injury:
- Unplug the foot controller of the appliance when leaving it unattended:
- Unplug the foot controller of the appliance before carrying out any maintenance.”
“CAUTION
-
This appliance complies
with EEC Directive
2004/108/EC covering
the electromagnetic
compatibility.
DISPOSAL:
This equipment is marked with
the recycling symbol. Do not
dispose this product as unsorted
municipal waste. Collection
of such waste separately for
special treatment is necessary.
(European Union only)
Moving parts-
To reduce risk of injury, switch off before
servicing. Close cover before operating
machine.”
To reduce the risk of electric shock:”
To reduce the risk of burns, re, electric shock, or injury to
persons: ”
FOOT CONTROL (USA &
Canada only)
Use Model KD-19 02 with t his sewing
machine.
POLARIZED PLUGS CAUTION
(USA & Canada only)
This appliance has a polarized plug (one
blade wider than the other). To reduce the
risk of electric shock, this plug is intended
to ft in a polarized outlet only one way. If the
plug does not t fully in the outlet, reverse
the plug. If it still does not fit, contact a
qualified electrician to install the proper
outlet. Do not modify the plug in any way.
“SAVE THESE
INSTRUCTIONS”
“This product is for household use, or
equivalent.”
