www.timberk.com • electric ceiling heater

1. Heater body

2. Protective grille

3. Heating element

4. Cover

1. Infrared heater - 1 pc

2. Set of fasteners - 1 pc

3. Operation manual - 1 pc

4. Warranty certificate - 1 pc

4. INFRARED HEATER DESCRIPTION

5. DELIVERY SET

Fig.2

1. Open the factory package and carefully remove the heater from it.

2. Take the set of fasteners.

3. Select the heater installation place on the ceiling or ceiling structural

elements with observation of minimum distances from objects and

minimum distance from the floor.

4. Install the brackets at distance from each other, securing them using a

chain or fasteners (fig. 3).

5. Suspend the heater on the brackets according to Fig. 3, first securing on

edge, then another. Make sure that screws are tightened firmly.

Infrared heater mounting

6. INSTALLATION

NOTE:

To improve the product quality, the design and

technical specifications of the infrared heater, as well

as its delivery set can be modified by the manufacturer

without preliminary notification.

WARNING!

Mounting of the infrared heater and its connection to the

electric mains should be carried out only by qualified

specialists according to the Electrical Installation

Regulations and Power System Safety Standards.

Fig.3
