6 DB168R/BD169R/BD169RG
280-8304-00
English
5. OPERATIONS
Basic Operations
CAUTION
Be sure to lower the volume before switching
off the unit power or the ignition key. The unit
remembers its last volume setting.
Turning on/off the power
1. Press the [SRC] button to turn on the power.
2. Press and hold the [SRC] button for 1 second
or longer to turn off the power for the unit.
Selecting a mode
1. Press the [SRC] button to change the
operation mode.
Radio mode ➜ CD mode ➜ Radio mode...
Adjusting the volume
1. Turning the [ROTARY] knob clockwise
increases the volume; turning it
counterclockwise decreases the volume.
∗ The volume level is from 0 (minimum) to
33 (maximum).
Audio Mode Adjustments
1. Press the [A-M] button to select the
adjustment mode. The mode switches as
follows each time the [A-M] button is pressed:
BASS ➜ TREB ➜ BAL ➜ FAD ➜ Previous
mode
∗ When the Z-Enhancer function is turned
on, BASS (bass) and TRE (treble) cannot
be selected.
2. Turning the [ROTARY] knob to adjust the
selected audio mode.
• BASS (bass): Adjustment range; –7 to +7
• TREB (treble): Adjustment range; –7 to +7
•
BAL (balance): Adjustment range; L13 to R 13
• FAD (fader): Adjustment range; F12 to R12
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
∗ The display returns to the previous mode 7
seconds after the adjustment.
Switching display
1. Press and hold the [BND] button, and then
press the [DISP] button to select the desired
display.
The display switches in the following order:
Main display ➜ Clock (CT) display ➜ Main …
∗ If the display is changed by other button
operation when the clock (CT) is displayed,
the clock display returns automatically after
the operation.
Setting the Z-Enhancer
This unit are provided with 3 types of sound
tone effects stored in memory. Select the one
you prefer.
1. Each time you press the [Z] button, the tone
effect changes in the following order:
“Z-ENHANCER 1” (bass emphasized) ➜
“Z-ENHANCER 2” (treble emphasized) ➜
“Z-ENHANCER 3” (bass and treble
emphasized) ➜ “Z-EHCR OFF” (no sound
effect) ➜ “Z-ENHANCER 1”...
Turning on/off MAGNA BASS
EXTEND
1. Press and hold the [A-M] button for 1 second
or longer to turn the MAGNA BASS EXTEND
and “M-B EX” in the display lights on or off.
CT (Clock Time) function
1. Press and hold the [BND] button, and then
press the [DISP] button, the display switches
to CT (Clock Time) from RDS data.
Triggered audio mute for cellular
telephones
This unit requires special wiring to mute the
audio signal automatically when a cellular
telephone rings in the car.
1. Press and hold the [BND] button, and then
press the [ ] to select the “TEL MUTE” or
“TEL OFF”.
TEL MUTE : mutes the audio sound.
TEL OFF : does not mute the audio sound.
Illumination dimmer function
When the illumination line of this unit is connected
with the car-side illumination signal line, the
display illumination of this unit dims in connection
with turning on the car-side illumination.
Turning the screen saver function
on or off
1. Press the [SS] button while keeping the
[BND] button pressed, to turn the screen
saver function on or off.
