www.timberk.com • electric air purifier
6
In case of emergency contact information listed in the table 2 below. If you
can not solve problems independently, to a service center.
8. TROUBLESHOOTING
Table 2
Problem Check Solution
Appliance does not turn ON
• Power
• Power
• Cover
• Plug in power cord
*Press the power button
*Make sure the cover is securely closed
Red «CLEAN CELL» indicator
has illuminated
Collector cell
Red «CLEAN CELL» indicator is a 60 day cleaning
reminder. Wash collector cell. Make sure it is
thoroughly clean before reinstalling
Red «CLEAN CELL» indicator
is blinking
Collector cell
• When a large particle is captured in the collector cell,
please restart your appliance
• A fast blinking light indicates the power supply
has shut down due to arcing or short circuit. The
cell should be inspected and cleaned, repaired, or
replaced
Collector cell does not remove
particles
Collector cell
• Clean the collector cell
• Collector cell may be damaged. Contact authorized
service center
Appliance sparks, crackles
and pops
Collector cell
• Sparking or poping noise (arcing)can occur
when a large particle is captured in the collector
cell or appliance is used in over damp rooms. If the
appliance is arcing excessively, the cell may be dirty.
Try cleaning the collector cell.
• If excessive arcing continues after proper cleaning,
the collector cell may be damage. If damager, contact
authorized service center.
«AUTO» light is blinking
Surroundings
Air qulity is very bad, please open the window to
improve the ventilation
Odor sensor
Odor sensor get malfunction, should be repaired
or replaced
ATTENTIONS!
• The collector cell may not require if «arcing» occurs.
Arcing is a snapping sound that occurs when large
particles are collected in the collector cell or the
appliance used in over-damp rooms.
• If prolonged or continuous arcing occurs, the collector
cell should be cleaned.
• To prevent damage to the components of the collector
cell, do not put in dishwasher or use a cotton swab.
• Tough residue such as tar from tobacco smoke may
need additional cleaning or longer soaking.
• The collector cell must be completely dry after cleaning
in order to operate properly. If the power supply detects
the collector cell is wet, it shuts down power to the cell
and cause the red «CLEAN CELL» indicator to blink
rapidly. Please re-dry the collector cell until the power
supply successfully restarts, the appliance will return to
its original speed and run as normal.
Cleaning the Pre-Filter
1.Unplug the appliance.
2.Open the front cover by gently pulling from the top corners.
3.Pull the pre-filter straight out of the cabinet.
4.Thoroughly rinse the pre-filter and let it air dry before placing it back in the
cabinet. Do not use heated or compressed air as part of the drying process.
5.Slide the pre-filter back into the unit.
6.Close the front cover securely.
Cleaning the Exhaust Grille
1. Remove the cleaning brush from the storage slot located under the cover.
2. Brush away debris that has collected between the grille slots.
3. Return the cleaning brush to the storage slot.
9.Place the collector cell back into the unit by sliding it straight in and turning
each knob to its locking position. The collector cell is specially designed so
that it can only be inserted in one direction.
10.Close the front cover securely.
