8
Chapter 1: Get Started with DX510
Article Name Location Description
Hard Drive
Tray Lock
Front
Each hard drive tray is equipped with one tray lock to
lock or unlock the tray to DX510.
eSATA Port
Back
The eSATA port is used to connect DX510 to DS1511+,
DS1010+, or DS710+.
Fan
Back
The fan is built to exhaust waste heat out of DX510.
If the fan is not working, DX510 will “beep” every few
seconds.
RESET Button
Back
The RESET button is used to restore the settings to the
factory default.
Power Port
Back
The power port is where you connect the power cord to
DX510.
LED Behavior
LED Behavior Description
POWER
Solid Blue
Power is on
Off
Power is off
eSATA
Solid Green
Synology DiskStation is connected
Off
Synology DiskStation is disconnected
RAID
Solid Green
Volume is created
Flashing Green
Volume is degraded
Off
Volume is crashed or not created
STATUS
Solid Green
System is functioning
Off
System is not working
ALERT
Solid Orange
Fan is not working
Off
Fan is functioning
Hard Disk
Status
(on tray)
Solid Green
Disk is ready and idle
Flashing Green
Disk is being accessed
Solid Orange
Read/write or other errors are encountered
Off
No internal disk is found
