through either a plug fused 3A or hardwired to a 2 fase spur
protected by 3A fuse.
2. Warning !
In certain circumstances electrical appliances may be a
danger hazard.
A) Do not check the status of the filters while the cooker
hood is operating
B) Do not touch bulbs or adjacent areas, during or straight
after prolonged use of the lighting installation.
C) Flambè cooking is prohibited underneath the cooker
hood
D) Avoid free flame, as it is damaging for the filters and
a fire hazard
E) Constantly check food frying to avoid that the
overheated oil may become a fire hazard
F) Disconnect the electrical plug prior to any
maintenance.
G) This appliance is not intended for use by young children
or infirm persons without supervision
H) Young children should be supervised to ensure they do
not play with the appliance
I) There shall be adequate ventilation of the room when
the rangehood is used at the same time as appliances
burning gas or other fuels
L) There is a risk of fire if cleaning is not carried out in
accordance with the instructions
This appliance conforms to the European Directive EC/2002/96,
Waste Electrical and Electronic Equipment (WEEE). By making
sure that this appliance is disposed of in a suitable manner,
the user is helping to prevent potential damage to the
environment or to public health.
The
symbol on the product or on the accompanying
paperwork indicates that the appliance should not be treated
as domestic waste, but should be delivered to a suitable
electric and electronic appliance recycling collection point.
Follow local guidelines when disposing of waste. For more
information on the treatment, re-use and recycling of this
product, please contact your local authority, domestic waste
collection service or the shop where the appliance was
purchased.
INSTALLATION INSTRUCTIONS
Assembly and electrical connections must be carried out by
specialised personnel.
• Electrical Connection
The appliance has been manufactured as a class II, therefore
no earth cable is necessary.
The connection to the mains is carried out as follows:
BROWN = L line
BLUE = N neutral
If not provided, connect a plug for the electrical load indicated
on the description label. Where a plug is provided, the
cooker hood must be installed in order that the plug is easily
accessible. An omnipolar switch with a minimum opening of
3mm between contacts, in line with the electrical load and
local standards, must be placed between the appliance and
the network in the case of direct connection to the electrical
network.
• The minimum distance between the support surfaces of
the cooking pots on the cooker top and the lowest part of
the cooker hood must be at least 65 cm.
If a connection tube composed of two parts is used, the
upper part must be placed outside the lower part. Do not
connect the cooker hood exhaust to the same conductor
used to circulate hot air or for evacuating fumes from other
appliances generated by other than an electrical source. In
the case of assembly of the appliance in the suction version
prepare the hole for evacuation of the air.
• We recommend the use of an air exhaust tube which has
the same diameter as the air exhaust outlet hole. If a pipe
with a smaller diameter is used, the efficiency of the product
may be reduced and its operation may become noisier.
• Warning: if the bulbs are not working, ensure that they are
screwed in fully.
• Installation
Prior to proceeding with the assembly operations (according
to the model that you have purchased), to facilitate handling
of the device, remove the grille as indicated in  gure 7 or the
aluminium panels as indicated in  gure 8.
• The appliance is equipped with 2 air outlets, to be used in
accordance with your speci c requirements: one is located
on the upper part of the appliance and the other at the rear
(Fig. 1A).
The  ange D, to which the air exhaust pipe is connected,
and a plug B, used to shut o the unused air outlet, are both
supplied with the product.
• This device may be installed in two di erent ways:
1. Fixing the hood to the lower part of the wall cabinet
(Fig.2)
- Make 4 holes in the wall cabinet respecting the measurements
indicated in  gures 2 A-2 C.
- Position the hood underneath the wall cabinet and  x it
into place using 4 screws (not supplied) suitable for the type
of cabinet.
2. Fixing the hood to the wall (Fig.2).
- Make 4 holes in the wall cabinet respecting the measure-
ments indicated in  gures 2 A-2 B. - Hang the hood on the
wall, using the 2 holes H, align it in a horizontal position and
x it de nitively to the wall using the two lower safety holes
I (Fig. 2B). For the various installations use screws and screw
anchors suited to the type of wall (e.g. reinforced concrete,
plasterboard, etc.). If the screws and screw anchors are provided
with the product, check that they are suitable for the type of
wall on which the hood is to be  xed.
• Mounting decorative ducts (optional)
- This hood model may have decorative ducts as optional
accessories - ask your retailer for information.
- Provide the electrical power supply within the space of the
decorative duct.
- If your appliance must be installed as an extractor version or
as a version with an external motor, make sure an air exhaust
hole is prepared ( g. 1A - 1C).
- Adjust the width of the upper duct support bracket (Fig.
3). Then  x it to the wall so that it is on the same axis as the
hood using screws A (Fig.3) and adhering to the distance from
the ceiling shown in (Fig. 2 B). Connect the  exible hose (not
supplied) to the  ange D ( g. 1A).
- Put the upper connector F into the lower connector G
and hang the decorative ducts on the wall, as indicated in
gure 4.
- Connect the  exible hose to the air exhaust hole made
previously (only in the extraction or external motor version).
- Pull out the top connector F as far as the bracket and  x it
- 19 -
