Clarion DB568RUSB [14/31] Radio mode operations

English

DB568RUSB

Manual tuning

There are 2 ways available: Quick tuning and

step tuning.

When you are in the step Tuning mode, the fre

quency changes one step at a time. In the quick

Tuning mode, you can quickly tune the desired

frequency.

1. Press the

[

BND

]

button and select the desired

band

(

FM or AM

(

MW/LW

))

∗ If “MANU” is not lit in the display, press and hold

the

[

BND

]

button for 1 second or longer.

“

MANU” is lit in the display and manual tuning

is now available.

2. Tune into a station.

Quick tuning:

Press and hold the

[

]

button for 1 second

or longer to begin station tuning.

Radio Mode Operations

Listening to the radio

1. Press the

[

SRC

]

button and select the Radio

mode, then the radio will be on.

2. To select a preset band, press the

[

BND

]

but-

ton, then select one of the preset bands such

as FM1, FM2, FM3 or AM

(

MW/LW

)

. Every

time the

[

BND

]

button is pressed, the display

will change as:

FM1 FM2 FM3 AM

(

MW/LW

)

FM1...

3. Press the

[

]

button to tune in the

desired station.

Seek tuning

There are 2 types of seek tuning: DX SEEK and

LOCAL SEEK.

DX SEEK can automatically tune in to receivable

broadcast stations; LOCAL SEEK can tune in to

only broadcast stations with a good reception

sensitivity.

1. Press the

[

BND

]

button and select the desired

band

(

FM or AM

(

MW/LW

))

∗ If “MANU” is lit in the display, press and hold

the

[

BND

]

button for 1 second or longer.

“

MANU” in the display goes off and seek tuning

is now available.

∗ If “TA” is lit in the display, TP stations are auto-

matically sought.

2. Press the

[

]

button to start automatic

station tuning.

DX SEEK

When the

[ ]

button is pressed, search will be

performing in the direction of higher frequencies.

When the

[ ]

button is pressed, search will be

performed in the direction of lower frequencies.

∗ When seek tuning starts, “DX” appears in the

display.

Step tuning:

Press the

[

]

button to perform manual

tuning.

∗ If no operation is performed for more than 7 sec-

onds, manual tuning is cancelled and the display

returns to the previous mode.

Manual memory function

1. Press the

[

BND

]

button, to select a band you

want to store in the memory.

2. Press the

[

]

button to tune into a desired

station.

3. Press and hold one of the

[

DIRECT

]

buttons for

2 seconds or longer to store the current station

into preset memory.

Preset memory function

Preset memory function can store up to 24 sta-

tions:

Six stations for each of FM1, FM2, FM3 and AM

(

MW/LW

)

LOCAL SEEK

If the button is pressed and held in position for

1 second or longer, local seek tuning will be en-

abled. Broadcast stations with good reception

sensitivity are selected.

∗ When local seeking starts, “LO” appears in the

display.
