Clarion DB568RUSB [7/31] Nomenclature
![Clarion DB568RUSB [7/31] Nomenclature](/views2/1003622/page7/bg7.png)
[
SENSOR
]
Receiver for remote control unit.
Operating range: 30° in all directions.
[
CD SLOT
]
CD insertion slot.
MAIN UNIT / APPAREIL PRINCIPAL / HAUPTGERÄT
/ APPARECCHIO PRINCIPALE / HOOFDTOESTEL
/ UNIDAD PRINCIPAL / HUVUDENHET / UNIDADE PRINCIPAL
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Hinweis: Bitte diese Seite ausfalten und beim Lesen der einzelnen Kapital die Frontdiagramme beachten.
Nota: Assicurarsi di aprire questa pagina e fare riferimento a questi diagrammi quando si legge ciascun capitolo.
Opmerking: Vouw deze pagina uit en zie tevens de afbeeldingen van het voorpaneel tijdens het doorlezen van de volgende hoofdstukken.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
Observera: Vik ut denna sida för att kunna se figurerna över bilstereons framsida medan du läser de olika kapitlen.
Nota: Certifique-se de abrir esta página e consulte os diagramas frontais conforme realiza a leitura de cada capítulo.
Note:
Be sure to read this chapter referring to the front diagrams of chapter “
2. CONTROLS” on page 5
(
unfold
)
.
CONTROLS / LES COMMANDES / REGLER / CONTROLLI
REGELAARS / CONTROLES / KONTROLLER / CONTROLOS
English
3. NOMENCLATURE
English
6 7
DB568RUSBDB568RUSB
5
DB568RUSB
English Français Deutsch Italiano
Nederlands
Español Svenska
Português
2.
Names of the Buttons and Their Functions
[
RELEASE
]
button
Press the
[
RELEASE
]
button to unlock the
detachable panel.
[
A
]
button
Press the button to switch to the ADJ mode.
Press and hold the button for 1 second or longer
to enter RDS ADJ mode.
[
,
]
buttons
Select a station while in the Radio mode or
select a track when listening to a CD/USB.
These buttons are used to make various
settings.
Press and hold the button for 1 second or longer
to enter the fast-forward or fast-backward in
CD/USB mode.
[
A-M
]
button
Press the button to switch to the Audio mode
(
Bass, Treble, Balance, Fader
)
.
Press and hold for 1 second or longer to turn on
or off the M-B EX mode.
[
BND
]
button
Switch the band, seek tuning or manual tuning
while in the Radio mode.
Play the first track while in the CD/MP3/WMA or
USB mode.
[
TA
]
button
Use the butt on to set the TA
(
Traff ic
Announcement
)
standby mode.
[
SRC
]
button
Press the button to turn on the power.
Press and hold the button for 1 second or longer
to turn off the power.
Switch the Operation mode among the Radio
mode, etc.
[
D
]
button
During Radio/CD mode, switch the display
indication
(
Main display, Clock display
)
.
During MP3/WMA/USB mode, switch the display
indication in the following order:
Track No./Play time Folder No./Track No.
Title Display Clock Display Track No./
Play time...
[
Z
]
button
Press the button to select one of the 3 types
of sound characteristics already stored in
memory.
[
T
]
button
Press the button to switch the track titles, while
in the MP3/WMA/USB mode.
Press and hold the button for 1 second or longer
to scroll the title during title display, while in the
MP3/WMA or USB mode.
[
UP
]
,
[
DN
]
buttons
Select the Folder
(
MP3/WMA disc or USB
drive
)
.
Press the button to select CD-DA or MP3/WMA
on a multi-session disc.
[
RDM
]
button
Perform random play while in the CD/MP3/WMA
or USB mode.
Press and hold the button for 1 second or longer
to perform folder random play while in the MP3/
WMA or USB mode.
[
]
button
Eject a CD when it is loaded in the unit.
Names of the Buttons and Their
Functions
[
USB PORT
]
USB drive insertion port.
[
SCN
]
button
Perform scan play for 10 seconds of each track
while in the CD/MP3/WMA or USB mode.
Press and hold the button for 1 second or
longer to perform folder scan play while in the
MP3/WMA or USB mode.
[
RPT
]
button
Repeat play while in the CD/MP3/WMA or USB
mode.
Press and hold the button for 1 second or longer
to perform folder repeat play while in the MP3/
WMA or USB mode.
[
DIRECT
]
buttons
Store a station into memory or recall it directly
while in the Radio mode.
[
]
button
Perform preset scan while in the Radio mode.
Press and hold the button for 2 seconds or
longer to perform auto store.
Play or pause a track while in the CD/MP3/WMA
or USB mode.
[
ROTARY
]
knob
Adjust the volume by turning the knob clockwise
or counterclockwise.
Use the knob to perform various settings.
