12. TROUBLE SHOOTING
Error message Possible causes What to do
No or bad signal
The antenna is not connecting
properly.
Adjust aerial.
Check the cable from the antenna. If
you cannot resolve the problem, you
may need to have your aerial and
installation tested by a professional.
The channel is
scrambled or not
available.
The channel has signal, but
no audio or video.
Confirm if the channel is available.
The channel is for data
broadcasting.
Cannot watch the channel in usual way.
The channel is
scrambled.
This digital terrestrial receiver
does not support the service
that enables to descramble
the scrambled channels.
The audio is not
available.
The channel has signal, but
no Audio.
Press the [RED] button to confirm if the
channel has Audio.
The antenna
cable is short-
circuited.
Antenna cable is shorten.
Antenna is internally shorten.
Antenna in port is inserted by
alien substance or damaged.
Replace antenna.
Remove the alien substance and
contact local service center if it is
damaged.
If the product does not work normally after completing the following trouble shooting, please
contact your local product distributor or service centre.
18 DTX501E
English
Owner’s
Manual
