ENGLISH
STAND FAN MW-3545 W
The fan is intended for artificial ventilation of the
room.
Description
1. Front safety grid
2. Blade clamp
3. Clamp ring with screw and nut
4. Blades
5. Rear grid fastening nut
6. Rear grid with carrying handle
7. Motor axis
8. Slope angle adjuster
9. Motor unit
10. Control panel
11. Motor unit clamp
12. Telescopic bar
13. Telescopic bar clamp
14. Decorative panel
15. Supports
16. Fastening screws
Control panel (10)
17. Power indicator
18. “SW” Oscillation mode indicator
19. “L, M, H” Blades rotation speed indicators
20. “0.5H/1H/2H/4H” automatic switch-off timer
operation time indicator
21. “ON/SPEED” on/speed operation mode button
22. “SWING” rotation mode button
23. “TIMER” timer operation time selection button
24. “OFF” fan switch-off button
Remote control (25)
26. “OFF” Switch-off button
27. “SWING” rotation mode button
28. “TIMER” timer operation time selection button
29. “MODE” air flow mode selection button:
– “NORMAL” – simple ventilation
– “NATURE” – natural wind
– “SLEEP” – calming wind
– “NORMAL” – simple ventilation
30. “ON/SPEED” switch-on/speed operation mode
selection button
31. Battery compartment lid
SAFETY MEASURES
Before using the electrical appliance, read this
instruction manual carefully, and keep it for further
reference.
Use the unit for intended purposes only, as specified
in this manual. Mishandling the unit can lead to its
breakage and cause harm to the user or damage to
his/her property.
•
Before switching the unit on for the first time,
make sure that your home mains voltage corre-
sponds to unit operating voltage.
•
Before using the unit, examine the power cord
closely and make sure that it is not damaged.
If you find that the power cord is damaged, do
not use the unit.
•
Do not use the fan outdoors.
•
Place the unit on a flat, dry and steady surface
away from sources of heat or open flame.
•
Do not use the unit near containers filled with
water, next to a kitchen sink, in wet basements or
near a swimming pool.
•
Do not immerse the fan, power cord and power
plug into water or any other liquids.
•
Do not touch the unit body and the power plug
with wet hands.
•
If the fan falls into water, unplug it before touch-
ing it and only then you may take the fan out of
water. Apply to the nearest authorized service
center for testing or repairing the unit at the con-
tact addresses given in the warranty certificate
and on the website www.maxwell-products.ru.
•
Make sure that the power cord does not contact
with hot surfaces and sharp furniture edges.
•
Do not switch the unassembled fan on.
•
Do not insert any foreign objects into the open-
ings of the fan protective grids to avoid injuries
or unit damage.
•
Do not touch the rotating blades during the fan
operation.
•
Do not place the fan near curtains or house plants.
•
It is not recommended to stay under the air flow
coming from the fan for a long time (especially
for children and elderly people).
•
Do not leave the operating unit unattended.
•
Unplug the fan before cleaning and when you
do not use the unit or before moving it to a
new place.
•
When unplugging the fan, pull the plug but not
the cord.
•
Clean the unit regularly.
•
Do not leave children unattended to prevent
using the unit as a toy.
•
For children safety reasons do not leave poly-
ethylene bags, used as packaging, unattended.
ATTENTION! Do not allow children to play with
polyethylene bags or packaging film. Danger of
suffocation!
•
Do not allow children to touch the unit body and
the power cord during the unit operation.
•
The unit is not intended for usage by physically
or mentally disabled persons (including children)
or by persons lacking experience or knowledge if
they are not under supervision of a person who
is responsible for their safety or if they are not
instructed by this person on the usage of the unit.
•
Do not use the fan if the blades, power cord
or power plug are damaged, if the fan works
improperly, after it was dropped or was damaged
in some other way.
•
Do not attempt to repair the unit. Do not disas-
semble the unit by yourself, if any malfunction is
detected or after it was dropped, unplug the unit
and apply to any authorized service center at the
contact addresses given in the warranty certificate
and on the website www.maxwell-products.ru.
•
Transport the unit in the original package.
•
For environment protection do not discard the
unit with usual household waste after its service
life expiration; apply to a specialized center for
further recycling.
•
Keep the unit in a dry cool place out of reach of
children and disabled persons.
THIS UNIT IS INTENDED FOR HOUSEHOLD USAGE
ONLY
BEFORE THE FIRST USE
After unit transportation or storage at low tempera-
ture keep it for at least three hours at room tempera-
ture before switching on.
Fan assembling
•
Unpack the unit and remove any stickers that can
prevent its operation.
•
Check the unit for damages, do not use it in case
of damages.
•
Set the supports (15) crosswise on a flat dry
surface.
•
Set the telescopic bar (12) on the supports (15)
and fix it with four fastening screws (16).
•
Unscrew and remove the clamp (13) by rotating it
counterclockwise, set the decorative panel (14) on
the telescopic bar (12). Set the clamp (13) back to
its place by turning it clockwise for several times.
•
Extend the bar (12) to the desired height and fix
it by tightening the clamp (13) with a slight effort
as you turn it clockwise.
•
Install the motor unit (9) on the telescopic bar
(12) until bumping and fix it with the clamp (11),
do not apply excessive effort when screwing the
clamp of the motor unit (11).
•
Set the rear grid (6) on the motor unit (9) match-
ing the guides on the motor unit (9) with the cor-
responding openings on the grid (6). The carry-
ing handle on the rear grid (6) should be turned
upwards.
•
Fix the rear grid (6) on the motor unit (9) with
the plastic nut (5) by screwing it clockwise until
bumping.
•
Put the blades (4) on the motor axis (7) matching
the groove on the blades with the clamp on the
motor axis and fix them with the plastic clamp (2)
rotating it counterclockwise and holding the
blades (4) with your free hand.
•
Set the nut and the fixing screw into the clamp
ring (3) sockets.
•
Match the front grid (1) and the rear grid (6), fix
them with the clamp ring (3) and tighten up the
clamp ring (3) by turning the fixing screw tight.
Note! For easy assembling of the fan grids first install
the clamp ring (3) on the rear grid (6) and tighten up
the fastening screw slightly. Install the bottom part of
the front grid (1) on the clamp ring (3). Then press
the bottom part of the front grid (1) to the clamp
ring (3) and squeezing both grids on the both sides
install the grid (1) under the clamp ring (3). Tighten
the fastening screw (4).
•
The fan is ready for operation.
USAGE
Before using the unit for the first time, make sure
that the voltage in your mains corresponds to the
unit operating voltage.
•
Insert the plug into the mains socket, you will
hear a sound signal and the light indicator (17)
indicating that the unit is connected to the mains
will light up on the control panel (10).
Note: every pressing of the control panel buttons
(21, 22, 23, 24) is accompanied by a sound signal.
•
Press the “ON/SPEED” button (21) the “L” oper-
ation mode indicator (19) will light up, you
will hear a sound signal, and the fan will start
operating.
•
Press the “ON/SPEED” button (21) again to
select the blades rotation speed; the light indi-
cators (19) inform about the selected blades
rotation speed;
–
“L” – low air flow speed
–
“M” – medium air flow speed
–
“H” – high air flow speed
•
Press the “SWING” button (22) to switch the 90°
oscillation operation mode of the fan on, the
“SW” indicator (18) will light up.
•
To stop the rotation mode, press the “SWING”
button (22) again, the “SW” indicator (18) will
go out.
•
Automatic switch-off timer operation time is
selected by the “TIMER” button (23), the light
indicators (20) will inform about the set time. You
can set the fan operation time from 0.5 hours to
7.5 hours (with 0.5 hours setting step).
•
To switch the timer off press the “TIMER” but-
ton repeatedly until all the indicators (20) go out.
•
To switch the fan off press the “OFF” button (24).
•
You may change and fix the position of the motor
unit (9) of the fan in accordance with the required
air flow angle in the vertical position, the fan slope
angle is set manually. To change the fan slope
angle loosen the adjuster (8) by turning it coun-
terclockwise, set the required slope angle of the
fan, and then tighten the adjuster (8) up by turn-
ing it clockwise. Clicking while the fan is being
tilted is normal.
Using the remote control (25)
To use the remote control (RC) (25) open the battery
compartment lid (31) and insert 2 “AAA” batteries
(not supplied with the unit) into the battery compart-
ment strictly following the polarity, close the battery
compartment lid (31).
If you do not use the unit for a long time, remove
the batteries from the battery compartment of the
remote control (25).
Note:
–
Replace the batteries in the remote control (25)
in time, to avoid damage of the remote control
(25) do not allow leaking of batteries.
–
Every pressing of the control panel (25) buttons
is accompanied by a sound signal.
–
Functions of the remote control (25) buttons
correspond to functions of the buttons on the
control panel (10).
•
Insert the power plug into the socket, the
power indicator (17) will light up on the control
panel (10).
•
Press the “ON/SPEED” button (30) on the remote
control (25), the “L” operation mode indicator
(19) will light up on the control panel (10), you
will hear a sound signal, and the fan will start
operating, by pressing the button (30) again you
may set the required blades rotation speed of
the fan, the light indicators (19) inform about the
selected speed:
–
“L” – low air flow speed
–
“M” – medium air flow speed
–
“H” – high air flow speed.
•
Consequently press the “MODE” button (29)
on the remote control (25) to select the air flow
mode. You may choose three modes:
–
“NORMAL” – simple ventilation; the air flow
speed depends on the mode selected by the
“ON/SPEED” button (30);
–
“NATURE” – natural wind; natural wind imita-
tion mode, the air flow speed is chaotically
changing: from soft breeze to strong gust
of wind.
–
“SLEEP” – calming wind; the air flow speed
is changing in cycles, constantly increasing
and decreasing.
–
“NORMAL” – simple ventilation; the air flow
speed depends on the mode selected by the
“ON/SPEED” button (30).
•
Select the operation time of the automatic
switch-off timer by consequently pressing the
“TIMER” button (29) on the remote control (25),
the light indicators (20) on the control panel (10)
will inform about the set operation time. You
can set the fan operation time from 0.5 hours to
7.5 hours (with 0.5 hours setting step). To switch
the timer off press the “TIMER” button (28)
repeatedly until all the indicators (20) go out.
•
Press the “SWING” button (27) on the remote
control (25) to switch the 90° oscillation opera-
tion mode of the fan on, the “SW” indicator (18)
will light up on the control panel (10). To switch
this function off or to set the unit body rotation
in the desired direction press the “SWING” but-
ton (27) again.
•
To switch the fan off press the “OFF” button (24).
MAINTENANCE AND CARE
•
Before cleaning the fan switch it off by pressing
the “OFF” button (24) on the control panel (10) or
the “OFF” button (26) on the remote control (25)
and unplug it.
•
Do not use abrasive cleaners and solvents to
clean the unit.
•
Clean the motor unit (9) with a slightly damp
cloth, and then wipe it dry.
•
If you need to clean the blades (4), unscrew the
nut on the ring (3), remove the ring (3), remove
the front grid (1), and then wipe the blades with a
slightly damp cloth.
•
Install the front grid (1) and the ring (3) back to
its place.
•
You may clean the fan blades with a vacuum
cleaner using a proper attachment.
•
Do not immerse the motor unit (9) of the fan into
water or any other liquids. Make sure that no liq-
uids get into the motor unit (9) of the fan to avoid
its damage and prevent risk of electric shock.
Storage
–
Unplug the fan and clean it.
–
Disassemble the fan, if needed.
–
Remove the ring (3), the front grid (1), unscrew
the blade clamp (2) by turning it clockwise,
remove the blades (4), unscrew the fixing nut of
the rear grid (5) and remove the grid (6).
–
Unscrew the clamp (11) and remove the motor
unit (9) from the telescopic bar (12).
–
Unscrew 4 nuts and remove the telescopic
bar (12) from the supports (15).
–
Pack the fan into the original package and put it
away for storage in a dry cool place away from
children.
DELIVERY SET
Motor unit – 1 pc.
Front grid – 1 pc.
Clamp ring with the screw and nut – 1 pc.
Blade clamp – 1 pc.
Blades – 1 pc.
Rear grid – 1 pc.
Telescopic bar with clamp and decorative
panel – 1 pc.
Supports – 2 pcs.
Screw – 4 pcs.
Remote control – 1 pc.
Instruction manual – 1 pc.
TECHNICAL SPECIFICATIONS
Power supply: 220-240 V ~ 50/60Hz
Maximum power: 40 W
Blades diameter: 40 cm (16”)
The manufacturer reserves the right to change
the specifications of the unit without a preliminary
notification.
Service life of the fan is 3 years
Guarantee
Details regarding guarantee conditions can be
obtained from the dealer from whom the appliance
was purchased. The bill of sale or receipt must be
produced when making any claim under the terms
of this guarantee.
Напольный вентилятор
MW-3545 W
4
RUS
Дата производства изделия указана в серийном номере на табличке с техническими
данными. Серийный номер представляет собой одиннадцатизначное число, первые
четыре цифры которого обозначают дату производства. Например, серийный номер
0606ххххххх означает, что изделие было произведено в июне (шестой месяц) 2006 года.
GB
A production date of the item is indicated in the serial number on the technical data plate.
A serial number is an eleven-unit number, with the first four figures indicating the production
date. For example, serial number 0606ххххххх means that the item was manufactured in June
(the sixth month) 2006.
4 5
ЗАПРЕЩЕНО УТИЛИЗИРОВАТЬ
С БЫТОВЫМ МУСОРОМ.
ОБРАТИТЕСЬ НА СООТВЕТСТВУЮЩИЙ
ПУНКТ ПЕРЕРАБОТКИ ЭЛЕКТРИЧЕСКОГО
И ЭЛЕКТРОННОГО ОБОРУДОВАНИЯ.
IM MW-3545.indd 2 31.10.2016 18:18:57

Содержание

Похожие устройства

Скачать
