Instructions for use

2. INSTALLATION AND REMOVAL OF THE MAXI-COSI TOBI

Installation with 3-point belt (follow red colour marks on product)

Only use the Maxi-Cosi Tobi on a front-facing seat that has been provided with an automatic 3-point belt,

provided it has been approved according to the ECE R16 standard or similar.

Correct fitting of the car seat belt is essential for the safety of your child. The car seat must be attached in

the correct sequence along the red marks on the Maxi-Cosi Tobi, for this see also the sticker on the side of

the Maxi-Cosi Tobi. Never fit the seat belt in a way other than that described!

Remove the headrest of the seat where the Maxi-Cosi Tobi is to be used in the car if it is in the way. Do not

forget to put the headrest back when the seat is used again.

A. Installation

• NOTE! Lock fold-down rear seats before installing the Maxi-Cosi Tobi.

• NOTE! In some cases, the seat belts are positioned too far forward. This will make proper installation

impossible. Try a different seat in this case.

• NOTE! Before the seat is installed, make sure that the belt tensioners are in the correct position by

pressing the release button (1). The belt tensioners should be horizontal.

• NOTE! Make sure that both seat belt clamps are open (2).

• Place the Maxi-Cosi Tobi on the car seat.

• Place the seat belt for the Maxi-Cosi Tobi along and over (4) the belt tensioners. Make sure that the hip

belt passes under the shell, over the red belt marks (3,1).

• Click the seat belt into the belt buckle of the car (3,2).

• NOTE! It may be the case that the buckle part of the seat belt is so long that the buckle protrudes above

the frame of the Maxi-Cosi Tobi. If this is so, the Maxi-Cosi Tobi cannot be secured properly. In that case,

choose another position in the car (5). Moreover, it may break the buckle!

• Slide the shoulder part of the seat belt, on the side where the belt buckle of the car is also located,

through the red belt slot on the backrest (6).

• Then pass the shoulder part along the red marks for the shoulder belt on the back of the Maxi-Cosi

Tobi (7).

• Slide this through the second red belt slot to the outside (7,2).

• Push the Maxi-Cosi Tobi firmly into the car seat (8,1) while at the same time pulling the shoulder belt tight

(8,2). The Maxi-Cosi Tobi is now securely in place in the car. Double-check this!

• First shut the belt clamp on the belt buckle side and then that on the other side, in the direction of the

roll-up mechanism (9).

• Finally, tighten the belt properly by turning the belt tensioner(s) a quarter of a turn upwards in the vertical

position (10). The seat belt is now fitted more tightly!

• In many cases this will result in a kink in the hip belt. However, this does not involve any danger for your

child and is part of the correct installation!

• NOTE! Make sure that both belt clamps on top of the seat are closed.

• NOTE! Make sure that the car seat belt is not twisted.
