Cybex Juno Fix группа 1, Black, Grey [11/24] Installation of the child seat with isofix connect system

With the ISOFIX CONNECT System you can secure the child seat safely in

the car and thus make your child safer. Your child is further protected by the

security of your car‘s three-point automatic seat belt.

NOTEĄ TСО ISЇFIБ КЧМСШЫКРО ЩШТЧЭЬ (Т) КЫО ЭаШ ЦОЭКХ ЫТЧРЬ ЩОЫ ЬОКЭ КЧН КЫО

located between the backrest and the seat of the car. If you are in any doubt,

МШЧЬЮХЭ вШЮЫ МКЫ’Ь ТЧЬЭЫЮМЭТШЧ ЦКЧЮКХ ПШЫ КЬЬТЬЭКЧМО.

If it is difficult to access the ISOFIX anchorage points (i) of your car, and to protect

the seat cover you can permanently fit the ISOFIX guides (u) provided in both

anchorage points. In many cars it is more effective to install the ISOFIX guides (u)

in an opposing direction.

To secure the CYBEX JUNO 2-FIX correctly, observe the following instructions:

NOTEĄ TКФО МКЫО ЭСКЭ ЭСО ЭаШ РЫООЧ ЬКПОЭв ТЧНТМКЭШЫЬ (б) ШЧ ЭСО ISЇFIБ МШЧЧОМЭШЫЬ

(а) КЫО ЧШЭ ЯТЬТЛХО. IП ЧОМОЬЬКЫв, ЫОХОКЬО ЭСО МШЧЧОМЭШЫЬ (а) Лв ЩЫОЬЬТЧР КЧН

ЩЮХХТЧР ЛКМФ ЭСО ЫОН ЫОХОКЬО ЛЮЭЭШЧ (в). RОЩОКЭ ЭСО ЩЫШМОЬЬ КЬ КЩЩЫШЩЫТКЭО ПШЫ ЭСО

second connector

NOTE! Please refer to the section „PLACING THE CHILD SEAT IN THE CAR“.

INSTALLATION OF THE CHILD SEAT WITH ISOFIX CONNECT

SYSTEM

• Activate the handle (v) on the underside of the child seat.

• Pull out the ISOFIX connectors (w) as far as possible.

• Turn the connectors 180°, so that they show in the direction of the ISOFIX

GUIDES (u).

• You can now secure your child in the child seat; see „SECURING THE CHILD“

• Push the two ISOFIX connectors (w) into the GUIDES (u) until they lock into place

on the anchorage points (i) with an audible „CLICK“.

• Make certain that the child seat is securely fixed in place by trying to pull it out.

• The green safety indicator (x) must be clearly visible on both red release buttons

(y).

• You can now use the handle (v) on the underside of the child seat to adjust the

position of the seat.
