Cybex Juno Fix группа 1, Black, Grey [7/24] Adjustiіg tї the bїdв siгe

ADJUSTIІG TЇ THE BЇDВ SIГE

For a proper height adjustment of the CYBEX Juno 2-fix a booster inlay (g)

is included and already inserted under the seat cover when purchased. It is

recommended to use this height adjustment inlay (g) between the age of 9 and

18 months. For children over 19 months the height adjustment inlay (g) may be

removed. Afterwards the height adjustment should be regulated by moving the

headrest (e) into the correct position. Pull the adjustment handle (h) in order to

release the headrest (e). The seat is correctly adjusted if you can fit 2 fingers

between the bottom edge of the headrest (e) and the shoulder of the child. Pull the

adjustment handle (h) in order to unlock the shoulder and headrest.

Note! Shoulder and headrest (e) need to be perfectly adjusted in height to provide

the best protection and comfort for your child and to also guarantee the optimal

position of the diagonal belt. The height of the shoulder and headrest can be

adjusted in 8 positions. The shoulder part is attached to the headrest and does not

have to be adjusted separately.

REMOVAL OF THE BOOSTER INLAY

• Open the press buttons at the front of the booster cover (d).

• Lift the booster cover until the height adjusting inlay (g) can be easily removed

from the front.

• Remove the height adjustment inlay (g) according to the above age

recommendation.

• Put the seat cover back in its original position and fasten the press buttons.
