Превью страниц Страница 9 / 68

Metabo SE 6000 620046000 [9/68] Overview

ENGLISHen

and comes into contact with your eyes, wash them

with clean water and seek medical attention

immediately!

LED lights (6): Do not observe the LED radiation

directly with optical instruments.

See page 2.

1 Belt hook (mains powered tools) *

2 Rotation selector switch

3Trigger switch

4 Lock button (continuous operation)

5Handle

6LED lights

7 Battery pack release button

8 Belt hook (cordless tools)*

9Battery pack *

10 Capacity and signal indicator *

11 Capacity indicator button *

12 Depth stop

13 screwdriver bit*

14 Bit holder

15 Screwdriver spindle

16 Closure sleeve

17 Stop sleeve

* depending on the model / features

6.1 For mains powered machines only

Before plugging in, check that the rated mains

voltage and mains frequency, as stated on the

type plate match your power supply.

Always install an RCD with a maximum trip

current of 30 mA upstream.

6.2 For cordless machines only

Battery pack

Charge the battery pack (9) before use.

If performance diminishes, recharge the battery

pack.

The ideal storage temperature is between 10°C and

30°C.

Li-Ion battery packs "Li-Power" have a capacity and

signal indicator (10):

- Press the button (11), the LEDs indicate the

charge level.

- If one LED is flashing, the battery pack is almost

flat and must be recharged.

Removing and inserting the battery pack

Removal:

Press the battery pack release button (7)

and pull the battery pack (9) forwards.

To insert:

Slide the battery pack (9) in until it

engages.

Installation of belt hook

The belt hook (8) may be screwed into place on the

left or the right (see illustration, page 2).

7.1 Setting the direction of rotation,

engaging the transporting safety device

(switch-on lock)

Do not activate rotation selector switch (2)

unless the motor has completely stopped.

See page 2:

R = Clockwise setting

L = Counter-clockwise setting

0 = Central position: transportation lock setting

(switch-on lock)

7.2 On/Off switch, modifying the speed

Switching on, speed: press the trigger switch (3).

Press in the trigger to increase the rotational

speed.

To switch off release the trigger switch.

Continuous activation: With the trigger (3)

pressed, push in the locking button (4) and

release the trigger. Press and release the trigger

again (3) to switch off.

In continuous operation, the machine

continues running if it is forced out of your

hands. Therefore, always hold the machine with

both hands using the handles provided, stand

securely and concentrate.

7.3 Screwdriver bit change

Inserting and removing the screwdriver bit:

- Remove the depth stop (12).

- Insert: Insert the screwdriver bit (13) in the bit

holder (14).

- Remove: Pull the screwdriver bit (13) from the bit

holder (14) using a pliers.

- Attach the depth stop (12) again:

turn and engage in position when mounted.

Note:

The bit holder (14) may be removed from the

screwdriver spindle if the sleeve (16) is pulled back.

Never use 25 mm long screwdriver

bits (13) in the screwdriver spindle

(15)! Removal is not possible! Only

use the bit holder (14)!

7.4 Working with depth stop

See page 2, illustration 2 a and 2 b.

To preset the screw insertion depth, one of the

screws to be inserted is fitted on the screwdriver bit

(13). Set the depth stop (12) by turning as follows:

a) Screws with heads designed to sit on top of the

material (socket-head screws, oval head screws,

hex screws):

the surface area of the screw head is 2 mm outside

the stop sleeve (17).

b) Flat head screws:

the area of the screw head is 2 mm outside the stop

sleeve (17).

Insert a screw as a test. Correct the screw depth if

necessary:
