REMOVING THE BLADE
1. Press and hold the spindle lock button.
2. Turn the hex-head bolt with a wrench until the spindle
locks.
3. Loosen the hex-head bolt by turning the wrench
anticlockwise.
4. Remove the hex-head bolt and the outer blade washer.
5. Retract the lower guard back as far as possible under
the upper guard.
6. Remove the saw blade.
ADJUSTING THE DEPTH OF CUT
See Figure 5-9.
1. Loosen the depth adjustment knob.
2. Slide the base plate to the desired depth using the
depth adjustment knob and then retighten securely.
NOTE: The depth of cut can be determined by the depth
scale or by measuring the distance by which the blade
protrudes from the base plate.
ADJUSTING THE ANGLE
See Figure 10-11.
1. Set the cutting angle to any position between 0° and
45°.
2. Loosen the bevel adjustment knob at the front of the
tool and move the base plate to the desired angle
using the bevel scale.
3. Retighten the bevel adjustment knob.
SWITCH
See Figure 12.
This tool is started and stopped by squeezing and
releasing the trigger switch. To prevent the tool from being
started accidentally, the trigger can only be operated if the
safety button is depressed fi rst. The safety button can be
depressed with the thumb leaving the other fi ngers free to
squeeze the trigger switch. It is not necessary to maintain
pressure on the safety button once the trigger switch has
been depressed.
OPERATION
DANGER
Keep hands away from the cutting area when operating
the tool. Keep the cord away from the cutting area and
position it so that it will not get caught on the workpiece
during the cutting operation.
When cutting, use steady and even pressure in order to
obtain a uniform cut; do not force. Cut at a speed suited to
the workpiece. Cut slowly if the workpiece is hard. Inspect
the saw blade frequently and replace or sharpen it if dull,
to avoid overloading the motor.
CUTTING POSITION
See Figure 15-16.
When cutting a workpiece at 0°, use point "A" of the base
plate line guide and move the saw along the pencilled
line you have drawn. When cutting at 45°, use point "B".
This line guide shows an approximate line of cut. Make a
sample cut in scrap lumber to determine the actual line
of cut.
CAUTION
When ripping, the rip fence should only touch the workpiece
slightly. Do not force.
LIVE TOOL INDICATOR
This tool features a live tool indicator which illuminates as
soon as the tool is connected to the supply. This warns the
user that the tool is connected and will operate when the
switch is pressed.
MAINTENANCE
After use, check the tool to make sure that it is in top
condition.
It is recommended that you take this tool to a Ryobi
Authorized Service Center for a thorough cleaning and
lubrication at least once a year.
Do not make any adjustments while the motor is running.
Always disconnect the power cord from the socket
before changing removable or expendable parts
before lubricating or working on the unit. Keep handles
dry, clean and free from oil and grease.
If the power supply cord is damaged, it must be replaced
only by the manufacturer or by an authorized service
center to avoid risk. Contact authorized service center.
WARNING
For greater safety and reliability, all repairs should be
performed by an authorised Ryobi Service Centre.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
of as waste. The machine, accessories
and packaging should be sorted for
environmental-friendly recycling.
