Hitachi DS18DSFLRC [11/88] English

English

(2) Regarding the temperatures of the rechargeable battery

The temperatures for rechargeable batteries are as

shown in Table 2, and batteries that have become hot

should be cooled for a while before being recharged.

Table 2 Recharging ranges of batteries

(3) Regarding recharging time

Depending on the combination of the charger and

batteries, the charging time will become as shown

in Table 3.

Table 3 Charging time (At 20°C)

NOTE

The charging time may vary according to

temperature and power source voltage.

4. Disconnect the charger’s power cord from the

receptacle

5. Hold the charger firmly and pull out the battery

NOTE

After charging, pull out batteries from the charger

first, and then keep the batteries properly.

How to make the batteries perform longer.

(1) Recharge the batteries before they become

completely exhausted.

When you feel that the power of the tool becomes

weaker, stop using the tool and recharge its battery.

If you continue to use the tool and exhaust the

electric current, the battery may be damaged and

its life will become shorter.

(1) Lamp indication

The indications of the lamp will be as shown in

Table 1, according to the condition of the charger

or the rechargeable battery.

3. Charging

When inserting a battery in the charger, the pilot

lamp will light up continuously in red.

When the battery becomes fully recharged, the pilot

lamp will blink in red. (At 1-second intervals.)

(See Table 1)

Table 1

Indications of the lamp

Before Blinks Lights for 0.5 seconds. Does not light

charging for 0.5 seconds. (off for 0.5 seconds)

Lights Lights continuously

Blinks Lights for 0.5 seconds. Does not light

for 0.5 seconds. (off for 0.5 seconds)

Blinks Lights for 1 second. Does not light

for 0.5 seconds. (off for 0.5 seconds)

Overheat

standby

While

charging

Charging

complete

Battery overheated.

Unable to charge.

(Charging will

commence when

battery cools)

Pilot lamp

(red)

Temperatures at which the

Rechargeable batteries

battery can be recharged

BSL1415, BSL1815 0°C – 50°C

Charger

UC18YGSL

Battery

BSL1415, BSL1815

Approx. 40 min.

(2) Avoid recharging at high temperatures.

A rechargeable battery will be hot immediately after

use. If such a battery is recharged immediately after

use, its internal chemical substance will deteriorate,

and the battery life will be shortened. Leave the

battery and recharge it after it has cooled for a while.

CAUTION

䡬 When the battery charger has been continuously

used, the battery charger will be heated, thus

constituting the cause of the failures. Once the

charging has been completed, give 15 minutes rest

until the next charging.

䡬 If the battery is recharged when it is warm due to

battery use or exposure to sunlight, the pilot lamp

blinks.

The battery will not be recharged. In such a case,

let the battery cool before charging.

PRIOR TO OPERATION

1. Setting up and checking the work environment

Check if the work environment is suitable by

following the precautions.

HOW TO USE

1. Confirm the clutch dial position (See Fig. 5)

The tightening torque of this unit can be adjusted

according to the clutch dial position, at which the

clutch dial is set.

(1) When using this unit as a screwdriver, line up the

one of the numbers “1, 3, 5 ... 22” on the clutch dial,

or the dots, with the triangle mark on the outer body.

(2) When using this unit as a drill, align the clutch dial

drill mark “

” with the triangle mark on the outer

body.

CAUTION

䡬 The clutch dial cannot be set between the numerals

“1, 3, 5 ... 22” or the dots.
