--- 6 ---
Screwdriver Machine screw
••••••••
6 mm (1/4")
Wood screw
••••••••••••
8 dia. x 100 mm (#20 x 4")
Drill Brick
••••••••••••••••••••••
16 mm (5/8") [Depth 30 mm (1-1/4")]
Metal
••••••
Mild steel 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Aluminum 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Wood
••••••••••••••••••••••
50 mm (2") [Thickness 18 mm (11/16")]
Mount type
••••••
Screw-on (UNF 1/2" --- 20)
Diameter
•••••••••
1.5 --- 13 mm (1/16" --- 1/2")
Low: 0 --- 400/min, High: 0 --- 1,800/min
Slip torque
••••••••
1.5 --- 7 N
•
m (15 --- 70 kgf
•
cm, 13 --- 61 in-lbs.) [22 stages]
Max. torque
•••••••
Low: 62 N
•
m (633 kgf
•
cm, 550 in-lbs.), High: 12 N
•
m (122 kgf
•
cm, 106 in-lbs.)
Fan cooled DC magnet motor
Trigger switch with pushing button for forward and reverse rotation changeover (with brake)
T-type (with soft-grip handle)
Body
••••••••
Glassfiber reinforced polycarbonate resin (black) and thermoplastic elastomer (green)
Battery
•••••
Glassfiber reinforced polyamide resin (black)
Charger
•••
ABS resin (black)
Sealed cylindrical nickel-cadmium storage battery
Nominal voltage
•••••••••••••••
DC 18 V
Nominal life
•••••••••••••••••••••
Charging/discharging: Approx. 1,000 times
Nominal capacity
•••••••••••••
2.0 Ah
Sealed cylindrical nickel-metal-hydride storage battery
Nominal voltage
•••••••••••••••
DC 18 V
Nominal life
•••••••••••••••••••••
Charging/discharging: Approx. 500 times
Nominal capacity
•••••••••••••
2.6/3.0 Ah
Overcharge protection system:
(1) Battery voltage detection (
2
V system) for Ni-Cd battery
Mi-MH battery temperature detection (dT/dt system) for Ni-MH battery
(2) Battery surface temperature detection (thermostat or thermistor)
(3) 120 minutes timer
Power input: 90 W
Charging time: Approx. 50 minutes [for type EB 1820L battery at 20ûC (68ûF)]
Approx. 60 minutes [for type EB 1826HL battery at 20ûC (68ûF)]
Approx. 70 minutes [for type EB 1830HL battery at 20ûC (68ûF)]
Operable ambient temperature range: 0 ûC --- 40ûC (32ûF --- 104ûF)
The maximum allowable temperature of the type EB 1820L battery is 60ûC (140ûF) and
the type EB 1826HL or EB 1830HL battery is 45ûC (113ûF).
Indication method of battery charging function:
5. SPECIFICATIONS
5-1. Model DV 18DMR
Capacity
Keyless chuck
(13VLRL-N)
Rotation speed (No-load)
Type of motor
Torque
Type of switch
Handle configuration
Enclosure
Battery
(Type EB 1820L)
Charger
(Model UC 24YFA)
Battery
(Type EB 1826HL/
EB 1830HL)
