6
English
MAINTENANCE AND INSPECTION
1. Inspecting the depressed center wheel
Ensure that the depressed center wheel is free of cracks
and surface defects.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Inspecting the carbon brushes (Fig. 8)
The motor employs carbon brushes which are
consumable parts. Since an excessively worn carbon
brush can result in motor trouble, replace the carbon
brushes with new ones having the same carbon brush
No. ⓐ shown in the fi gure when it becomes worn to or
near the “wear limit” ⓑ. In addition, always keep carbon
brushes clean and ensue that they slide freely within the
brush holders.
4. Replacing carbon brushes (Fig. 8)
Disassemble the brush caps with a slotted-head
screwdriver. The carbon brushes can then be easily
removed.
5. Replacing supply cord
If the replacement of the supply cord is necessary, it has
to be done by Hitachi Authorized Service Center to avoid
a safety hazard.
6. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
GUARANTEE
We guarantee Hitachi Power Tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the Power Tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a Hitachi Authorized Service Center.
IMPORTANT
Correct connection of the plug
The wires of the main lead are coloured in accordance
with the following code:
Blue: — Neutral
Brown: — Live
As the colours of the wires in the main lead of this tool may
not correspond with the coloured markings identifying the
terminals in your plug proceed as follows:
The wire coloured blue must be connected to the terminal
marked with the letter N or coloured black. The wire
coloured brown must be connected to the terminal marked
with the letter L or coloured red. Neither core must be
connected to the earth terminal.
NOTE:
This requirement is provided according to BRITISH
STANDARD 2769: 1984.
Therefore, the letter code and colour code may not be
applicable to other markets except The United Kingdom.
Information concerning airborne noise and vibration
The measured values were determined according to
EN60745 and declared in accordance with ISO 4871.
Measured A-weighted sound power level:
99 dB (A) (G23SU)
100 dB (A) (G23SWU)
Measured A-weighted sound pressure level:
88 dB (A) (G23SU)
89 dB (A) (G23SWU)
Uncertainty K: 3 dB (A)
Wear hearing protection.
Vibration total values (triax vector sum) determined
according to EN60745.
Surface grinding:
Vibration emission value
a
h
,
AG
= 5.1 m/s
2
(G23SU)
5.3 m/s
2
(G23SWU)
Uncertainty K = 1.5 m/s
2
The declared vibration total value has been measured in
accordance with a standard test method and may be used
for comparing one tool with another.
It may also be used in a preliminary assessment of exposure.
WARNING
○ The vibration emission during actual use of the power
tool can diff er from the declared total value depending in
the ways in which the tool is used.
○ Identify safety measures to protect the operator that
are based on an estimation of exposure in the actual
conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is
switched off and when it is running idle in addition to the
trigger time).
● Information about power supply system of nominal
voltage 230 V~
Under unfavorable mains conditions, this power tool
may cause transient voltage drops or interfering voltage
fl uctuations.
This power tool is intended for the connection to a power
supply system with a maximum permissible system
impedance Z
MAX
of 0.28 Ohm at the interface point (power
service box) of the user’s supply.
The user has to ensure that this power tool is connected
only to a power supply system which fulfi lls the requirement
above.
If necessary, the user can ask the public power supply
company for the system impedance at the interface point.
NOTE
Due to HITACHI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
0000Book_G23SU.indb 60000Book_G23SU.indb 6 2015/01/05 16:34:292015/01/05 16:34:29
