15
English
GB
f) Blade depth and bevel adjusting locking levers must be
tight and secure before making the cut. If blade adjustment
shifts while cutting, it may cause binding and kickback.
g) Use extra caution when sawing into existing walls or
other blind areas. The protruding blade may cut objects that can
cause kickback.
Lower guard function
a) Check the lower guard for proper closing before each
use. Do not operate the saw if the lower guard does not
move freely and close instantly. Never clamp or tie the
lower guard into the open position. If the saw is accidentally
dropped, the lower guard may be bent. Raise the lower guard with
the retracting handle and make sure it moves freely and does not
touch the blade or any other part, in all angles and depths of cut.
b) Check the operation of the lower guard spring. If the
guard and the spring are not operating properly, they must
be serviced before use. Lower guard may operate sluggishly due
to damaged parts, gummy deposits, or a build-up of debris.
c) The lower guard may be retracted manually only for
special cuts such as "plunge cuts" and "compound cuts".
Raise the lower guard by the retracting handle and as soon
as the blade enters the material, the lower guard must be
released. For all other sawing, the lower guard should operate
automatically. NOTE Alternate wording for "retracting handle" is
possible.
d) Always observe that the lower guard is covering the
blade before placing the saw down on bench or oor. An
unprotected, coasting blade will cause the saw to walk backwards,
cutting whatever is in its path. Be aware of the time it takes for the
blade to stop after switch is released.
Additional Safety and Working Instructions
Wear ear protectors. Exposure to noise can cause hearing loss.
Use protective equipment. Always wear safety glasses when
working with the machine. The use of protective clothing is recom-
mended, such as dust mask, protective gloves, sturdy non-slip
footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to health.
Do not inhale the dust. Use a dust absorption system and wear a
suitable dust protection mask. Remove deposited dust thoroughly,
e.g. with a vacuum cleaner.
Do not use saw blades not corresponding to the key data given in
these instructions for use.
Do not use abrasion disks in this machine!
Do not x the on/o switch in the "on" position when using the saw
hand-held.
WORKING INSTRUCTIONS
Adapt the feed speed to avoid overheating the blade tips.
MAINS CONNECTION
Connect only to single-phase AC system voltage as indicated on
the rating plate. It is also possible to connect to sockets without an
earthing contact as the design conforms to safety class II.
Appliances used at many dierent locations including wet room
and open air must be connected via a residual current device (FI,
RCD, PRCD) of 30mA or less.
Only plug-in when machine is switched o.
Do not let any metal parts enter the airing slots - danger of short
circuit!
Keep mains lead clear from working range of the machine. Always
lead the cable away behind you.
Before use check machine, cable, safety harness and plug for any
damages or material fatigue. Repairs should only be carried out by
authorised Service Agents.
SPECIFIED CONDITIONS OF USE
This electronic circular saw can cut lengthways and mitre accura-
tely in wood.
MAINTENANCE
Always disconnect the plug from the socket before carrying out any
work on the machine.
Be sure to disconnect the tool from the power supply before
attaching or removing the saw blade.
Clean tool and guarding system with dry cloth.
Certain cleaning agents and solvents are harmful to plastics and
other insulated parts.
The ventilation slots of the machine must be kept clear at all times.
Remove dust regularly. Remove the sawdust which has accummu-
lated inside the saw in order to avoid the risk of re.
Keep the apparatus handle clean, dry and free of spilt oil or grease.
Check the function of guards.
Regular maintenance and cleaning provide for a long service life
and safe handling.
If the supply cord of this power tool is damaged, it must be
replaced by a specially prepared cord available through the service
organization.
Use only AEG accessories and spare parts. Should components
need to be replaced which have not been described, please contact
one of our AEG service agents (see our list of guarantee/service
addresses).
If needed, an exploded view of the tool can be ordered. Please
state the Article No. as well as the machine type printed on the
label and order the drawing at your local service agents or directly
at: Techtronic Industries GmbH, Max-Eyth-Straße10, 71364Win-
nenden, Germany.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product described
under “Technical Data” fullls all the relevant provisions of the
directives
2011/65/EU (RoHS)
2006/42/EC
2014/30/EU
and the following harmonized standards have been used.
EN 60745-1:2009 + A11:2010
EN 60745-2-5:2010
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
EN 61000-3-2:2014
EN 61000-3-11:2000
EN 50581:2012
Winnenden, 2016-03-25
