ENGLISHen

Recommended oscillating frequency settings:

Plastic materials . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Metal, Plexiglas

, old coats of paint . . . . . . . . 3-4

Coarse and fine sanding, polishing, wood. . . 5

The best way to determine the ideal setting is through

a practical trial.

7.3 TurboBoost switch

Actuate the TurboBoost switch (3) during operation to

switch on additional power reserves for maximum

material removal rate.

7.4 Dust extraction

To optimise the dust extraction performance, fit the

sanding disc such that the holes on the sanding disc

(9) and sanding plate (11) are aligned.

Own extraction system:

Fit the dust collection box

(6) onto the exhaust nozzle until it engages. To

remove it, pull out the dust collection box (6).

To optimise the extraction performance, empty the

dust collection box (6) in good time and clean the filter

(8).

External dust extraction:

Fit a suitable dust

extractor.

Empty dust collection box (6).

- Open cleaning flap (7).

- Remove fluted filter (8) and knock off dust stuck to

filter or remove with brush.

You can also clean fluted filter (8) under running

water (but make sure to dry the filter before use!).

- Empty the dust collection box (6), clean it thor-

oughly and ensure that any remaining dust is

removed.

- When inserting, ensure that the fluted filter (8) is

inserted in the lateral guides.

Clean the machine regularly.

This includes

vacuum cleaning the ventilation louvres on the motor.

Replacing worn sanding plate (11)

- Remove fixing screws (on lower side of sanding

plate).

- Take off sanding plate.

- Sanding plate (as a spare part), see page 2.

- Mount sanding plate.

- Re-insert the fixing screws on the lower side of the

sanding plate (the screw must be inserted in the

existing thread pitch) and tighten (tightening torque

= 3.5 Nm +/- 0.2 Nm).

Use only genuine Metabo accessories.

For a complete range of accessories, see

www.metabo.com or the main catalogue.

Repairs to electrical tools must be carried out by qual-

ified electricians ONLY!

If the mains connection cable of this machine is

damaged, it must be replaced by the manufacturer or

an authorized service centre to avoid hazard.

If you have Metabo electrical tools that require

repairs, please contact your Metabo service centre.

For addresses see www.metabo.com.

You can download spare parts lists from

www.metabo.com.

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.

Only for EU countries: Never dispose of power

tools in your household waste! In accordance

with European Guideline 2002/96/EC on used

electronic and electric equipment and its implemen-

tation in national legal systems, used power tools

must be collected separately and handed in for envi-

ronmentally compatible recycling.

Explanatory notes on the specifications on page 3.

Changes due to technological progress reserved.

A = Dimensions of sanding plate

= Nominal power input

= Power output

= Idle speed (setting wheel)

0, TB

= Idle speed (TurboBoost switch)

1, TB

= Speed at rated load (TurboBoost switch)

= Oscillating frequency at idle speed (setting

wheel)

0, TB

= Oscillating frequency at idle speed

(TurboBoost switch)

1, TB

= Oscillating frequency at rated load

(TurboBoost switch)

S = Oscillating circuit diameter

m = Weight without mains cable

Measured values determined in conformity with

EN 60745.

Machine in protection class II

Alternating current

The technical specifications quoted are subject to

tolerances (in compliance with the relevant valid

standards).

Emission values

Using these values, you can estimate the emis-

sions from this power tool and compare these with

the values emitted by other power tools. The actual

values may be higher or lower, depending on the

particular application and the condition of the tool or

power tool. In estimating the values, you should also

include work breaks and periods of low use. Based

on the estimated emission values, specify protective

measures for the user - for example, any organisa-

tional steps that must be put in place.

Vibration total value (vector sum of three directions)

determined in accordance with EN 60745:

= Vibration emission value (surface grinding)

= Uncertainty (vibration)

Typical A-effective perceived sound levels:

=Sound pressure level

=Acoustic power level

, K

= Uncertainty

Wear ear protectors!

8. Cleaning, Maintenance

9. Accessories

10. Repairs

11. Environmental Protection

12. Technical Specifications
