Installation

MOUNTING:

1. After reading precaution, decide where you are going to install the unit. Also, see the picture below.

2. Once the location has been determined, remove the plastic decorative panels from left and right sides

of amplifier then place the amplifier in position. Using a felt tip pen or pencil mark the four holes to be

drilled for mounting. NEVER use the amplifier as a template for drilling. It is very easy to damage the

amplifier surface in manner.

3. Remove the amplifier. Drill four holes into mounting surface.

4. If possible, test the system to ensure it is operating correctly before final mounting of the amplifier.

5. Mount the amplifier using the supplied 4 self-threading screws.

Accessories

Amplifier 1 pc

Screw 4 pcs

Rubber washer 4 pcs

Bushing 4 pcs

Flat washer 4 pcs

Spring washer 4 pcs

Instruction manual 1 pc

Warranty card 1 pc

Consumer information 1 pc
