* Some development
may be required in
specific user cases
to support some
of these protocols
in the field as they
mature over time.
OPERATIONAL
VIDEO STANDARD
NTSC/PAL
SCANNING SYSTEM
Progressive scan
IMAGE SENSOR
H2W2PRV3: 1/2.7" 2 MP CMOS
H2W4PRV3: 1/3" 4 MP CMOS
NUMBER OF PIXELS (H×V)
H2W2PRV3: 1920×1080 (2 MP)
H2W4PRV3: 2688×1520 (4 MP)
MINIMUM ILLUMINATION
0.01 lux, F1.4 (color)
0 lux (B/W with IR LEDs on)
S/N RATIO
50 dB or more
ELECTRONIC SHUTTER
SPEED
1/31/100 000 s
IR DISTANCE
Up to 65 ft (20 m), depending
on scene reflectance
DAY/NIGHT
Auto(ICR)/Color/BW
BACKLIGHT COMPENSATION
BLC/HLC/WDR (120 dB)
WHITE BALANCE
Auto/Sunny/Night/Outdoor/
Manual
GAIN CONTROL
Auto/Manual
NOISE REDUCTION
3DNR
PRIVACY MASKING
Up to 4 areas
MOTION DETECTION
Up to 4 areas
LENS
2.8 mm, F2.0
HORIZONTAL ANGLE OF VIEW
H2W2PRV3: 120°
H2W4PRV3: 106°
CORRIDOR MODE
Yes
VIDEO
VIDEO COMPRESSION
H.264/H.264H/H.264B/MJPEG
FRAME RATE
H2W2PRV3: 25/30 fps @ 1920
×1080 (2 MP), 25/30fps @
1280×1024 (SXGA), 25/30fps @
1280×960 (1.3 MP), 1280×720
(720p), 704×576/704×480 (D1),
352×288/352×240 (CIF)
H2W4PRV3: 20 fps @
2688×1520 (4 MP); 20 fps @
2560 × 1440 (4 MP); 25/30
fps @2304×1296 (3 MP),
1920×1080 (1080p), 25/30fps
@ 1280×1024 (SXGA), 25/30fps
@ 1280×960 (1.3 MP), 1280×720
(720p), 704×576/ 704×480 (D1),
352×288/352×240 (CIF)
BIT RATE (H.264)
32 Kbps – 10 Mbps
LOCAL STORAGE
microSD, 128 GB max.
AUDIO
COMPRESSION
G.711, AAC
INTERFACE
Built-in mic
NETWORK
ETHERNET
RJ45 (10/100BaseT)
PROTOCOLS*
IPv4/IPv6, HTTP, HTTPS, SSL,
TCP/IP, UDP, UPnP, ICMP, IGMP,
SNMP, RTSP, RTP, SMTP, NTP,
DHCP, DNS, PPPoE, DDNS, FTP, IP
Filter, QoS, Bonjour, 802.1X
COMPATIBILITY
ONVIF Profile S, Profile G
MAX. USER ACCESS
20 users
MOBILE DEVICES
HonView Touch for iPhone and
Android devices
ELECTRICAL
POWER SUPPLY
PoE (802.3af), 12 VDC
POWER CONSUMPTION
5.0 W max.
MECHANICAL
DIMENSIONS
106.0 × 50.3 mm (4.17 × 1.98 in.)
WEIGHT
1.04 lb (0.47 kg)
CONSTRUCTION
Die-cast aluminum housing
with powder coat
CONSTRUCTION
COLOR
RAL 9003 (White)
ENVIRONMENTAL
TEMPERATURE
30°C to 60°C (22°F to 140°F)
RELATIVE HUMIDITY
095%, non-condensing
INGRESS PROTECTION
IP66
VANDAL RESISTANCE
IK10
REGULATORY
EMISSIONS
FCC Part 15, CE (EN 55032)
IMMUNITY
CE (EN 501304)
SAFETY
North America UL Listed to UL/
CSA 609501, CE (EN 609501)
SPECIFICATIONS
TDN WDR IR Micro Dome Camera
