Performance Series IP Cameras
FEATURES AND BENEFITS
HEW2PRW1/HEW4PRW3
HEW2PR1/HEW4PR3
TDN WDR IR Ball Camera
HEW2PR1/HEW2PRW1/HEW4PR3/
HEW4PRW3
Honeywell’s new Performance Series IP ball cameras are taking quality
and reliability to the next level, offering outstanding picture clarity and
hassle-free flexible system integration.
Superior Image Quality
• Full HD 1080p 25/30 fps image with a 1/2.7" 2 megapixel sensor
or full HD 4 MP 20 fps image with a 1/3" 4 megapixel sensor
• Wide Dynamic Range, up to 120 dB, ensures glare-free images
• True Day/Night provides vivid color images by day and
clear black-and-white images at night with ICR
• Excellent low-light performance with 3D noise
reduction, saving storage and bandwidth
Flexible Surveillance Solution
• 3.6 mm or 2.8 mm fixed lens at F2.0
• H.264 and MJPEG codec, triple stream support
• IR LEDs provide up to 130 ft (40 m) of illumination in dimly
lit or nighttime scenes (depending on scene reflectance)
• Smart IR technology provides even distribution of IR
• Weatherproof (IP66) camera housing
• –30°C to 60°C (–22°F to 140°F)
working temperature
• Plug-and-play compatible with Honeywell 4/8/16-channel
Performance Series Embedded NVRs
Easy to Install and Use
• Built-in PoE (Power over Ethernet) eliminates need
for separate power supply and associated wiring;
12 VDC inputs where PoE power is unavailable
• Remote configuration through web client or from the NVR
• 1/2.7" 2 MP or 1/3"
4 MP progressive scan
imager
• 3.6 mm or 2.8 mm
fixed lens
• True day/night
(IR-cut filter)
• Wide dynamic range
up to 120 dB
• Low-light
performance down to
0.01 lux (color) or 0 lux
with IR LEDs on
• Up to 130 ft (40 m) IR
illumination,
depending on scene
reflectance
• H.264 Main Profile
compression
• Triple stream support
• Supports up to 20
connections
• Corridor mode
• PoE, 12 VDC support
• Plug-and-play
compatible with
Honeywell
Performance Series
Embedded NVRs
• Weatherproof housing
with IP66 ingress
protection rating
Market Opportunities
These flexible, fully featured cameras are ideal
for a wide range of surveillance applications,
providing excellent picture quality at
minimal bandwidth while offering reliable
protection against dust, dirt, and water.
Содержание
- Easy to install and use 1
- Fe atures and benefits 1
- Flexible surveillance solution 1
- Hew2pr1 hew2prw1 hew4pr3 hew4prw3 1
- Market opportunities 1
- Performance series ip cameras 1
- Superior image quality 1
- Tdn wdr ir ball camera 1
- A still image of the event through email and or ftp setup can be done using the web client or from an nvr 2
- Camera tampering automated responses include sending a notification through email ftp and or http and sending 2
- Dimensions 2
- Hew2pr1 hew2prw1 hew4pr3 hew4prw3 2
- Security features 2
- Tdn wdr ir ball camera 2
- The camera can be configured to automatically detect and respond to events such as motion in the scene and or 2
- 30 c to 60 c 22 f to 140 f 3
- 93 mm 4 7 3 9 in 3
- 95 non condensing 3
- Ce en 50130 4 3
- Die cast aluminum housing with powder coat 3
- Fcc part 15 ce en 55032 3
- Hew2pr w 1 4 w max hew4pr w 3 3 w max 3
- Hew2pr1 ral7022 gray hew2prw1 ral 9003 white hew4pr3 ral 7022 gray hew4prw3 ral 9003 white 3
- In the field as they 3
- Iphone ipad android 3
- Ipv4 ipv6 http https ssl tcp ip udp upnp icmp igmp snmp rtsp rtp smtp ntp dhcp dns pppoe ddns ftp ip filter qos bonjour 802 x 3
- Lb 0 5 kg 3
- Lb 0 7 kg 3
- Mature over time 3
- May be required in 3
- Of these protocols 3
- Onvif profile s 3
- Poe ieee 802 af class 0 12 vdc 3
- Rj 45 10 100base t 3
- Some development 3
- Specific ations 3
- Specific user cases 3
- Tdn wdr ir ball camera 3
- To support some 3
- For more information 4
- Honeywell security and fire 4
- Ordering 4
- Specific ations 4
- Tdn wdr ir ball camera 4
