Honeywell HEW2PRW1 [3/4] Tdn wdr ir ball camera
![Honeywell HEW2PRW1 [3/4] Tdn wdr ir ball camera](/views2/1370845/page3/bg3.png)
* Some development
may be required in
specific user cases
to support some
of these protocols
in the field as they
mature over time.
OPERATIONAL
VIDEO STANDARD
NTSC/PAL
SCANNING SYSTEM
Progressive scan
IMAGE SENSOR
HEW2PR(W)1: 1/2.7" 2 MP CMOS
HEW4PR(W)3: 1/3” 4 MP CMOS
NUMBER OF PIXELS (H×V)
HEW2PR(W)1: 1920×1080
HEW4PR(W)3: 2688×1520
MINIMUM ILLUMINATION
0.01 lux, F2.0 (color)
0 lux (with IR LEDs on)
S/N RATIO
50 dB or more
ELECTRONIC SHUTTER SPEED
Auto, Manual, 1/31/100 000 s
IR DISTANCE
Up to 130 ft (40 m), depending
on scene reflectance
DAY/NIGHT
Auto(ICR)/Color/BW
BACKLIGHT COMPENSATION
BLC/HLC/WDR (120 dB)
WHITE BALANCE
Auto/Sunny/Night/Outdoor/
Customized
GAIN CONTROL
Auto/Manual
NOISE REDUCTION
3DNR
PRIVACY MASKING
Up to 4 areas
LENS
HEW2PR(W)1: 3.6 mm, F2.0
HEW4PR(W)3: 2.8 mm, F2.0
HORIZONTAL ANGLE OF VIEW
HEW2PR(W)1: 91°
HEW4PR(W)3: 110°
CORRIDOR MODE
Yes
VIDEO
VIDEO COMPRESSION
H.264/H.264H/H.264B/MJPEG
RESOLUTION
HEW2PR(W)1: 1080p
(1920×1080)/720p
(1280×720)/D1
(704×576/704×480)/
CIF (352×288/352×240)
HEW4PR(W)3: 4 MP
(2688×1520/2560×1440)/3 MP
(2304×1296)/1080p
(1920×1080)/720p (1280×
720)/D1 (704×576/704×480)/
CIF (352×288/352×240)
FRAME
RATE
MAIN
STREAM
HEW2PR(W)1: 1080p/720p
(125/30 fps)
HEW4PR(W)3: 4 MP (120 fps)/
3 MP (125/30 fps)
SUB STREAM
HEW2PR(W)1: D1/CIF
(125/30 fps)
HEW4PR(W)3: D1/CIF (120 fps)
TRIPLE
STREAM
HEW2PR(W)1: 720p (113/4 fps)
HEW4PR(W)3: 720p (120 fps)
BIT RATE (H.264)
32 Kbps10 Mbps
NETWORK
ETHERNET
RJ45 (10/100BaseT)
PROTOCOLS*
IPv4/IPv6, HTTP, HTTPS, SSL,
TCP/IP, UDP, UPnP, ICMP, IGMP,
SNMP, RTSP, RTP, SMTP, NTP,
DHCP, DNS, PPPoE, DDNS, FTP, IP
Filter, QoS, Bonjour, 802.1X
COMPATIBILITY
ONVIF Profile S*
MAX. USER ACCESS
20 users
MOBILE DEVICES
iPhone, iPad, Android
ELECTRICAL
POWER SUPPLY
PoE IEEE 802.3af Class 0, 12 VDC
POWER CONSUMPTION
HEW2PR(W)1: 4.0 W max.
HEW4PR(W)3: 3.7 W max.
MECHANICAL
DIMENSIONS
106.0 × 93.7 mm (4.17 × 3.69 in.)
PRODUCT WEIGHT
1.04 lb (0.47 kg)
PACKAGE WEIGHT
1.43 lb (0.65 kg)
CONSTRUCTION
Die-cast aluminum housing with
powder coat
CONSTRUCTION
COLOR
HEW2PR1: RAL7022 (Gray)
HEW2PRW1: RAL 9003 (White)
HEW4PR3: RAL 7022 (Gray)
HEW4PRW3: RAL 9003 (White)
ENVIRONMENTAL
TEMPERATURE
30°C to 60°C (22°F to 140°F)
RELATIVE HUMIDITY
095%, non-condensing
INGRESS PROTECTION
IP66
REGULATORY
EMISSIONS
FCC Part 15, CE (EN 55032)
IMMUNITY
CE (EN 501304)
SAFETY
North America UL Listed to UL/
CSA 609501, CE (EN 609501)
North America UL Listed to UL/CSA
6095022, CE (EN 6095022)
SPECIFICATIONS
TDN WDR IR Ball Camera
