14
AXIS 210/211 - Video Streams
Video Streams
The AXIS 210/211 provides several different image and video formats. The type to use
depends on your requirements and on the properties of your network.
The Live View page in the AXIS 210/211 provides access
to Motion JPEG and MPEG-4
video streams, as well as to single JPEG images. Other applications and clients can also
access these video streams/images directly, without going via the Live View page.
Video Stream Types
Motion JPEG
This format uses standard JP
EG still images in the video stream. These images are then
displayed and updated at a rate sufficient to create a stream that shows constantly updated
motion.
The Motion JPEG stream uses
considerable amounts of bandwidth, but also provides
excellent image quality and access to each and every individual image contained in the
stream.
Note also that multiple clients a
ccessing Motion JPEG streams can use different image
settings.
MPEG-4
This is a video compression standard that makes go
od use of bandwidth, and which can
provide high-quality video streams at less than 1 Mbit/s.
The MPEG-4 standard provides scope for a large range of different coding tools for use by
various applications in d
ifferent situations, and the AXIS 210/211 provides certain subsets
of these tools. These are represented as Video object types, which are selected for use with
different viewing clients. The supported video object types are:
• Simple - sets the coding type
to H.263, as used by e.g. QuickTime™.
• Ad
vanced Simple - sets the coding type to MPEG-4 Part 2, as used by AMC (AXIS
Media Control)
When using MPEG-4 it is also possible to control the bit rate, which in turn allows the
amount
of bandwidth usage to be controlled. CBR (Constant Bit Rate) is used to achieve a
specific bit rate by varying the quality of the MPEG-4 stream. When using VBR (Variable
Bit Rate), the quality of the video stream is kept as constant as possible, at the cost of a
varying bit rate.
Notes:
•MPEG-4 is licensed technology. The AXIS 210/211 includes one viewing client license. Installing
additional unlicensed copies of the viewing client is prohibited. To purchase additional licenses,
contact your Axis reseller.
•All clients viewing the MPEG-4 stream must use the same set of coding tools.
