Axis 210 [34/60] Ip address filtering

AXIS 210/211 - System Options

System Options

Security

User access control is enabled by default, when the administrator sets the root password on

first access. An administrator can set up other users, by giving these user names and

passwords. It is also possible to allow anonymous viewer login, which means that anybody

may access the Live View page, as described below:

Users - the user list displays the authorized users

and user groups (levels):

User Settings - ch

eck the relevant checkboxes to enable:

• An

onymous viewer login - allows any viewer direct access to the Live View

page.

• Maximum number of s

imultaneous viewers - enter a value here to restrict the

number of unicast viewers accessing the unit. This is useful if you need to save

on bandwidth. (Note that

all multicast viewers count as 1 viewer.)

IP Address Filtering

Enable IP Address Filtering- To allow or deny access to the AXIS 210/211 Network Camera

check the box Enable IP address filtering. Once enabled, the IP addresses in the list will be

allowed or denied access according to the choice made in the drop-down list Allow/Deny

the following IP addresses.

The administrator can add up to 256 IP address entries to the

list (a single entry can

contain multiple IP addresses). The users from these IP addresses need to be specified in the

user list with the appropriate access rights. This is done from Setup > System Options >

Security > Users.

Referrals

To prevent unauthorized clients from including the video stream from the cameras into

external Web pages, check the Referrals checkbox and enter the IP address or Host name

of the computer that hosts the Web pages with the included video stream. Several IP

addresses/host names can be defined and are separated by semicolons (;). This option is

only applicable to Motion JPEG video streams.

Viewer Provides the lowest level of access, which only allows access to the Live View page.

Operator An operator can view the Live View page, create and

modify event types and adjust certain other

settings. Operators have no access to the System Options.

Administrator An administrator has unrestricted access to all the setup tools and

can determine the registration of

all other users.
