Basic Operations
English
18
DXZ778RUSB
3-3. Push the [
P.CH
] button upward or
downward to adjust the “
HPF
”, “
HPF
SLOPE
”, “
PHASE
”, “
LPF
” and “
LPF
SLOPE
”.
●
HIGH
●
MID
●
SUB-W (3WAY)/REAR (2WAY)
3-4. Press the [ ] button to store into
memory.
●
Setting the time alignment
The distance from the listener up to each
speaker can be entered in 2.3 cm steps, and the
time that the sound reaches the listener from
each speaker can be adjusted (Time alignment).
2-1. Select “
T ALIGNMENT
”.
3-1. Press the [ ] button.
3-2. Push the [
SEEK PANEL
] leftward or
rightward and select from:
Items Adjustable
range
Initial value
HPF THRGH
(through), 25
Hz to 20 kHz
2 kHz
HPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
PHASE NOR (normal),
REV (reverse)
NOR (normal)
Items Adjustable
range
Initial value
LPF 630 Hz to 10
kHz, THRGH
(through)
2 kHz
LPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
HPF THRGH
(through), 25
Hz to 10 kHz
THRGH
(through)
HPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
PHASE NOR (normal),
REV (reverse)
NOR (normal)
• HIGH
• HPF
• HPF SLOPE
• PHASE
• MID
• LPF
• LPF SLOPE
• HPF
• HPF SLOPE
2WAY mode
• PHASE
• REAR
• LPF
• LPF SLOPE
• HPF
• HPF SLOPE
• PHASE
• HIGH
(Front speaker (high))
(Front speaker (mid))
(Rear speaker)
(High pass filter)
(HPF slope)
(Phase)
(Low pass filter)
(LPF slope)
Items Adjustable
range
Initial value
LPF 25 Hz to 10
kHz, THRGH
(through)
80 Hz
LPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
HPF THRGH
(through), 16
Hz to 250 Hz
THRGH
(through)
HPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
PHASE NOR (normal),
REV (reverse)
NOR (normal)
• HIGH
• HIGH L SP
• HIGH R SP
• MID
• MID L SP
• MID R SP
• SUB-W
• SUB-W L SP
• SUB-W R SP
• HIGH
3WAY mode
(Front speaker (high))
(Front speaker (mid))
(Subwoofer)
(Left)
(Right)
(Left)
(Right)
(Left)
(Right)
