cooking, never use the bottom shelf and never place anything

on the bottom of the oven when it is in operation because

this could damage the enamel. Always place your cookware

(dishes, aluminium foil, etc. etc.) on the grate provided with

the appliance inserted especially along the oven guides.

Models with Hob Gas Burner Safety Devices to

Prevent Leaks (only on certain models)

These models can be identified by the presence of the

device itself (see detail C).

Oven and Grill Control Knob (M)

This knob allows you to select the various features of the oven

and to set the most appropriate cooking temperature from among

those indicated on the knob itself (between Min and Max).

To light the oven burner, hold a lighted match or lighter near the

“F” hole and, at the same time, press down and turn the oven

knob counter-clockwise to the Max setting.

Since the cooker is equipped with a safety device which

makes it necessary to keep the knob pressed in for about 6

seconds after the burner has been lighted to allow the gas

to pass through freely.

The cooking temperature is selected by matching the desired

temperature with the reference mark on the panel; the complete

range of temperatures is shown below.

The temperature setting is then automatically reached and kept

constant by the thermostat (which is controlled by the knob).

To use the grill, turn the knob clockwise till to setting

after holding a lighted match or a lighter close to the grill burner.

In the grill burner equipped with a safety device, the knob

must be held pressed in for about 6 seconds in order to

activate the flame failure device. In this way the infrared ray

comes on for browning the food or cooking roast, chops, sausages,

roast-beef, etc.; for grill cooking, place a drip-pan under the grill to

catch the grease.

Important Notice: In the event the flame for the oven acciden-

tally goes out, turn the control knob for the burner to the off

position and do not relight the burner for at least one minute.

Important: when using the grill, the oven door must be left partly

open by positioning the deflector “D” between door and panel to

prevent the cooker knobs from overheating.

Oven Light Button (O)

This button is marked by the

symbol and switches on

the light inside the oven so that you can monitor the cook-

ing process without opening the door.

The rotisserie (only a few models)

To operate the rotisserie, proceed as follows:

a) place the dripping-pan on the 1st rack;

b) insert the special rotisserie support on the 4th rack

and position the spit by inserting it through the special

hole into the rotisserie at the back of the oven;

c) to start the spit, press the button “O”.

Cooking Control Timer Knob (only a few models)

Some models are equipped with a timer program to control when

the oven shuts off during cooking. To use this feature, you must

wind the “P” knob one full turn in the counter-clockwise direction

5; Then, turn the knob in the clockwise direction 4, to set the

time by matching up the indicator on the control panel with the

number of minutes on the knob.

Caution

Keep children away from the oven door when in use be-

cause it becomes very hot.

Storage recess below the oven (only a few models)

Below the oven a recess can be used to contain cooking

pans and cooker accessories. Moreover, during oven

operation, it may be used to keep food warm.To open the

storage is necessary turn it downwards.

Caution: this storage recess must not be used to store

inflammable materials.

Min • 150 • 180 • 220 Max
