5.5.3 NULL Message

The NULL message returned from the monitor is used in the following cases;



To tell the controller that the monitor does not have any answer to give to the host (not

read y or not exp ecte d)



A null mess age will be returned by the monitor if the “Start Proof of Play” command is

sent and the monitor has already started Proof of Play.



A null message will be returned by the monitor if the “Stop Proof of Play” command is sent

and the monitor has not started Proof of Play.



Complete "NULL Message" command packet as follows;

01h-30h-30h-41h-42h-30h-34h-02h-42h-45h-03h-CHK-0Dh

SOH-'0'-'0'-'A'-'B'-'0'-'4'-STX-'B'-'E'-ETX-CHK- CR

STX

Command code

ETX

'B' 'E'
