![Nec MultiSync V754Q [31/141] Advanced](/views2/1375342/page31/bg1f.png)
(31/139)
Item
OP code
page
OP code Parameter Remarks
H ZOOM 11h 2Dh 0-89(59h): No mean
90(5Ah): 90%
91(5Bh): 91%
|
100(64h): 100%
|
300(12Ch): 300%
The
following
commands can
also be used.
OP code page
02h
OP code 6Ch
Parameter
0: No mean
1: 100%
2: 101%
|
201(C9h):
300%
V ZOOM 11h 2Eh 0-89(59h): No mean
90(5Ah): 90%
91(5Bh): 91%
|
100(64h): 100%
|
300(12Ch): 300%
The
following
commands can
also be used.
OP code page
02h
OP code 6Dh
Parameter
0: No mean
1: 100%
2: 101%
|
201(C9h):
300%
H POS 02h CCh 0: Left side
|
200(C8h): Right side
V POS 02h CDh 0: Down side
|
200(C8h): Up side
ADVANCED
OVER SCAN 02h E3h 0: No mean
1: OFF
2: ON
DEINTERLACE 02h 25h 0: No mean
1: Off
2: ON
ADAPTIVE CONTRAST 02h 8Dh 0: No mean
1: Off
2: LOW
4: High
NOISE REDUCTION *1 02h 26h 0: Off
|
3: High
Page02
OPcode20h
also
works as
same.
TELECINE 02h 23h 0: No mean
1: Off
2: Auto
ROTATION
IMAGE FLIP 02h D7h 0: No mean
1: NONE
2: H FLIP
3: V FLIP
4: 180 ROTATE
OSD FLIP 10h B8h 0: No mean
1: OFF
2: ON
SPECTRAVIEW ENGINE 11h 47h 0: No mean
1: Off
2: ON
RESET
(PICTURE)
02h CBh 0: No mean
2: Reset
Picture category
Momentary
