(30/130)
Item OP
code
page
OP code Parameter Remarks
PICTURE MODE 02h 1Ah 0: No mean
1: sRGB
3: HIGHBRIGHT
4: STANDARD
5: CINEMA
8: CUSTOM1
9: CUSTOM2
13(0Dh): SVE-1 SETTING
14(0Eh): SVE-2 SETTING
15(0Fh): SVE-3 SETTING
16(10h): SVE-4 SETTING
17(11h): SVE-5 SETTING
sRGB:
PC mode
only
CINEMA:
A/V mode
only
SVE-(1-5)
SETTINGS
PRESET 10h 51h 0: No mean
1: sRGB
2: Adobe RGB SIM
3: DCI SIM
4: REC-Bt709
5: HIGHBRIHGT
6: FULL
7: DICOM SIM
8: PROGRAMMABLE1
9: PROGRAMMABLE2
10(0Ah): PROGRAMMABLE3
11(0Bh): PROGRAMMABLE4
12(0Ch): PROGRAMMABLE5
13(0Dh): eciRGB v2
LUMINANCE 02h B3h 0(0%): Dark
|
600(0258h)(100%): Bright
Note: Conversion equation
Value = (OSD Value/100)
*(600-40)+40
WHITE 00h 54h 0:2600K
|
74(4Ah):10000K
00h 14h 2: NAVIVE
11(0Bh): CUSTOM
WHITE x 10h 52h 250(00FAh): 0.250
|
480(01E0h): 0.480
WHITE y 10h 53h 250(00FAh): 0.250
|
480(01E0h): 0.480
GAMMA 02h 68h 0: No mean
5: DICOM SIM.
9: CST
11(0Bh): sRGB
12(0Ch): L STAR
CUSTOM VALUE 02h E8h 0: 0.5(MIN)
|
350(015Eh): 4.0(MAX)
BLACK 10h 54h 1: 0.1(MIN)
|
50(32h): 5.0(MAX)
RED x 10h 55h 550(0226h): 0.550
|
800(0320h): 0.800
RED y 10h 56h 200(00C8h): 0.200
|
400(0190h): 0.400
GREEN x 10h 57h 100(0064h): 0.100
|
350(015Eh): 0.350
