(35/130)
Item OP
code
page
OP code Parameter Remarks
OS D
LANGUAGE 00h 68h 0: No mean
1: ENGLISH
2: GERMAN
3: FRENCH
4: SPANISH
5: JAPANESE
6: ITALIAN
7: SWEDISH
9: RUSSIAN
14(0Eh): CHINESE
OSD Language
MENU DISPLAY TIME 00h FCh 0-1: Do not set.
2: 10s
3: 15s
|
48(30h): 240s
5sec/step
OSD POSITION X 02h 38h 0: Left
|
255(FFh): Right
Y 02h 39h 0: Down
|
255(FFh): Up
INFORMATION OSD 02h 3Dh 0:Disable information OSD
3-10(0Ah):
OSD timer [seconds]
MONITOR
INFORMATION
MODEL NAME
Refer to section 12
SERIAL Refer to section 12
FIRMWARE1 Refer to section 16
FIRMWARE2
FIRMWARE3
FIRMWARE4
CARBON
SAVINGS
10h 10h
(g)
/11h
(kg)
0 – 999(3E7h)(g)
0 – 65535(FFFF
ｈ
)(kg)
Read Only
CARBON
USAGE
10h 26h
(g)
/27h
(kg)
0 – 999(3E7
ｈ
)(g)
0 – 65535(FFFF
ｈ
)(kg)
Read Only
OSD TRANSPARENCY 02h B8h 0: No mean
1: OFF
2: ON
OSD ROTATION 02h 41h 0: Landscape
1: Rotated
INPUT NAME Refer to section 18
NAME RESET
MEMO 10h BAh 0: No mean
1: Display a Memo
2: Undisplay a Memo
RESET
(OSD)
02h CBh 0: No mean
7: Reset OSD category
Momentary
MULTI DIS PLA Y
MONITOR ID 02h 3Eh 1-100:ID
GROUP ID 10h 7Fh 0: No assignment
1: Group A
2: Group B
3: Group AB
4: Group C
5: Group AC
|
1023(3FFh):Group
ABCDEFGHIJ
Bit0:Group A
Bit1:Group B
Bit2:Group C
Bit3:Group D
Bit4:Group E
Bit5:Group F
Bit6:Group G
Bit7:Group H
Bit8:Group I
Bit9:Group J
