(42/130)
Item OP
code
page
OP code Parameter Remarks
PICTURE NUMBER 10h B5h If MULTI PICTURE is set PIP
0: No mean
2: 2WINDOWS, PIP
3: 3WINDOWS, PIP
If MULTI PICTURE is set PBP
0: No mean
1: 2WINDOWS, PBP1
3: 3WINDOWS, PBP1
4: 3WINDOWS, PBP2
5: 3WINDOWS, PBP3
6: 4WINODWS, PBP1
MULTI PICTURE INPUT 02h 73h 0: No mean
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
ACTIVE PICTURE 11h 0Bh 0: No mean
1: PICTURE1
2: PICTURE2
3: PICTURE3
4: PICTURE4
ROTATE ROTATE ALL 11h 16h 0: No mean
1: OFF
2: ON
PICTURE1 11h 12h
PICTURE2 11h 13h
PICTURE3 11h 14h
PICTURE4 11h 15h
STILL CAPTURE 02h 76h 0: OFF
1: CAPTURE
Momentary
SIGNAL INFORMATION 02h EAh 0: No mean
1: OFF
2: ON
TV-CHANNEL UP/DOWN 00h 8Bh 0: No mean
1: UP
2: DOWN
This
operation
requires
supported
option TV
tuner.
TEMPE RATU RE S ENSO R
SELECT TEMPERATURE SENSOR 02h
78h 0: No mean
1: SENSOR #1
2: SENSOR #2
3: SENSOR #3
READOUT A TEMPERATURE 02h 79h Returned value is 2's
complement.
Refer to section 6.2
Read only
CARBO N FO OTPR INT
READOUT CARBON FOOTPRINT
(g)
10h 10h 0:
|
999(3E7h):
Read only
READOUT CARBON FOOTPRINT
(kg)
10h 11h 0:
|
65535(FFFFh):
Read only
READOUT CARBON USAGE
(g)
10h 26h 0:
|
999(3E7h):
Read only
