(41/130)
Item OP
code
page
OP code Parameter Remarks
INPUT 11h 06h 0: No mean
3: DVI1
4: DVI2
13(0Dh): OPTION
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
131(83h): HDMI4
132(84h): PRESET1
133(85h): PRESET2
134(86h): PRESET3
The
following
commands can
also be used.
OP code page
00h
OP code 60h
Parameter
0: No mean
3: DVI1
4: DVI2
13: OPTION
15: DPORT
16: DPORT2
17: HDMI1
18: HDMI2
AUDIO INPUT 02h 2Eh 0: No mean
1: LINE IN
4: HDMI
6: OPTION
7: DPORT
8: DPORT2
10(0Ah): HDMI2
11(0Bh): HDMI3
12(0Ch): HDMI4
VOLUME UP/DOWN 00h 62h 0: whisper
|
100(64h): loud
MUTE 00h 8Dh 0: UNMUTE(Set only)
1: MUTE
2: UNMUTE
SCREEN MUTE 10h B6h 0: No mean
1: SCREEN MUTE ON
2: SCREEN MUTE OFF
MTS 02h 2Ch 0: No mean
1: Main
2: Sub
3: Main + Sub
This
operation
requires
supported
option TV
tuner.
PICTURE MODE 02h 1Ah 0: No mean
1: sRGB
3: HIGHBRIGHT
4: STANDARD
5: CINEMA
8: CUSTOM1
9: CUSTOM2
13(0Dh): SVE-1 SETTING
14(0Eh): SVE-2 SETTING
15(0Fh): SVE-3 SETTING
16(10h): SVE-4 SETTING
17(11h): SVE-5 SETTING
sRGB:
PC mode
only
CINEMA:
A/V mode
only
ASPECT 02h 70h 0: No mean
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
6: DYNAMIC
7: 1:1 (Off/dot by dot)
WIDE:
A/V mode only
MULTI PICTURE MODE ON/OFF
STILL ON/OFF
02h 72h 0: No mean
1: Off
2: PIP
4: STILL
5: PBP(PBP1, PBP2, PBP3)
