Списки команд RS-232 Страница: 51

Nec UM301Wi (Multi-Touch) [51/119] Data part

©NEC Display Solutions, Ltd. 2014-2017 51

Response

 When the command succeeds

22h 1Fh <ID1> <ID2> 02h <DATA01> <DATA02> <CKS>

Data part

Item Description

DATA01 Operation

00h MOVE

01h STORE

02h RESET

DATA02 Execution result

00h Ended successfully.

FFh Ended with an error.

 When the command fails

A2h 1Fh <ID1> <ID2> 02h <ERR1> <ERR2> <CKS>
