3.34 [ 078-2. RUNNING STATUS REQUEST ]
Gets the information about the operation status of the projector.
Command
00h 85h 00h 00h 01h 01h 87h
Response
When the command succeeds
20h 85h <ID1> <ID2> 10h <DATA01> - <DATA16> <CKS>
Data part
Item Description
DATA01 - 02 Reserved for the system
DATA03 Power status
00h Standby FFh Not supported
01h Power on
− −
DATA04 Cooling process
00h Not executed FFh Not supported
01h During execution
− −
DATA05 Power On/Off process
00h Not executed FFh Not supported
01h During execution
− −
DATA06 Operation status
00h Standby (Sleep) 0Fh Standby (Power saving)
04h Power on 10h Network standby
05h Cooling FFh Not supported
06h Standby (error)
− −
DATA07 - 16 Reserved for the system
When the command fails
A0h 85h <ID1> <ID2> 02h <ERR1> <ERR2> <CKS>
